2009 Dahon Speed TR

Original specifications: SRAM X7 · 8-speed · mechanical rear derailleur · 20" wheels · 30.6 lb published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #19199
Model year
2009
Category
Folding
Sizes
One size fits all
Colors
Forest
Weight
30.6 lb
In this record
26 specifications · archived image
Model history 3 other years

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors
Forest
Frame
4130 butted chromoly
Original equipment
Folding Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build4130 butted chromoly · Folding Mix · 20" wheels

Historical catalog variants

Archived sizes and colors

1 item record

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

one size fits all

Published colors

Forest
View 1 archived size/color combination
SizeColor
one size fits allForest

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material4130 butted chromoly
ForkIntegrated
Fork MaterialUnicrown

Drivetrain

Component GroupFolding Mix
ShiftersSRAM Dual Drive
Rear DerailleurSRAM X.7
CranksetSugino XD, 46 teeth
Bottom BracketSealed cartridge
CassetteShimano HG
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC Z82
PedalsMKS EZY

Brakes

BrakesKinetix SpeedStop V brakes, Avid FR-5 levers

Cockpit & Contact Points

Headset1 1/8" Dahon Fusion XP+
HandlebarKinetix Pro
Handlebar ExtensionsNot included
StemRadius VRO
SaddleBioLogic Aria
SeatpostBioLogic Zorin PostPump, 34.0mm diameter

Wheels & Tires

HubsFront: Kinetix Pro, Rear: SRAM Dual Drive
RimsKinetix Comp double wall
SpokesStainless, double-butted
Spoke NipplesBrass
Front Tire20 x 2.00" Schwalbe Big Apple
Wheel Size20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes46T · 11–32T · 8-speed
Lowest1.44:1 Highest4.18:1 Total range291%
Estimated speed At 90 RPM Lowest gear7.7 mph Highest gear22.4 mph

Uses front tire 20×2; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z82
Retailer offers
Front tire · Original
20 x 2.00" Schwalbe Big Apple
Brake pads · Original
Kinetix SpeedStop V brakes

Avid FR-5 levers

More parts (3)Fewer parts
Pedals · Original
MKS EZY
Rear derailleur · Original
SRAM X.7
Seatpost · Original
BioLogic Zorin PostPump

34.0mm diameter

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
20 x 2.00" Schwalbe Big Apple
Drivetrain
8-speed
Seatpost diameter
34 mm
Bottom bracket / shell
Sealed cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Integrated · Unicrown

Archived: Group: Folding Mix · Shifters: SRAM Dual Drive · Rear derailleur: SRAM X.7 · Crankset: Sugino XD, 46 teeth · Bottom bracket: Sealed cartridge · Cassette: Shimano HG · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z82

Archived: Brakes: Kinetix SpeedStop V brakes, Avid FR-5 levers

Archived: Wheel size: 20" wheels · Rims: Kinetix Comp double wall · Hubs: Front: Kinetix Pro, Rear: SRAM Dual Drive · Front tire: 20 x 2.00" Schwalbe Big Apple

Controls and contact points

Archived: Headset: 1 1/8" Dahon Fusion XP+ · Handlebar: Kinetix Pro · Stem: Radius VRO · Seatpost: BioLogic Zorin PostPump, 34.0mm diameter · Saddle: BioLogic Aria · Pedals: MKS EZY
