SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Velopedia Bicycle Archive
Original specifications: SRAM X7 · 8-speed · mechanical rear derailleur · 20" wheels · 26.5 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #19190Browse other years
Compare side by side
2009 archived details
Clues, not proof of model year. Colors vary and components may have been replaced.
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 double butted aluminum |
| Fork | Kinetix Q |
| Fork Material | Springer |
| Rear Shock | X-Fusion air |
| Component Group | Folding Mix |
|---|---|
| Shifters | SRAM Twist |
| Rear Derailleur | SRAM X.7 |
| Crankset | Sugino XD |
| Bottom Bracket | Sealed cartridge |
| Cassette | Shimano HG |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC Z82 |
| Pedals | Suntour Folding alloy |
| Brakes | Avid Single Digit 7 brakes, Avid Speed Dial 7 levers |
|---|
| Headset | 1 1/8" Dahon Fusion+ |
|---|---|
| Handlebar | Kinetix Pro |
| Handlebar Extensions | Not included |
| Stem | Radius V forged |
| Saddle | Kore XC I-Beam |
| Seatpost | Kore I-Beam, 34.0mm diameter |
| Hubs | Front: Kinetix Neutron, Rear: Kinetix Comp |
|---|---|
| Rims | Kinetix Comp double wall |
| Spokes | Stainless |
| Spoke Nipples | Brass |
| Front Tire | 20 x 1.50" Schwalbe Marathon Racer |
| Wheel Size | 20" wheels |
No specifications match. Try a component name or clear your search.
Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.
Your changes apply to this calculation. The archived build stays unchanged.
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability

Replacement option
34.0mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Archived specifications for reference. Check the fitted parts before ordering.
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Archived: Frame: TIG-welded · Fork: Kinetix Q · Springer
Archived: Fork: Kinetix Q · Rear shock: X-Fusion air
Archived: Group: Folding Mix · Shifters: SRAM Twist · Rear derailleur: SRAM X.7 · Crankset: Sugino XD · Bottom bracket: Sealed cartridge · Cassette: Shimano HG · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z82
Archived: Brakes: Avid Single Digit 7 brakes, Avid Speed Dial 7 levers
Archived: Wheel size: 20" wheels · Rims: Kinetix Comp double wall · Hubs: Front: Kinetix Neutron, Rear: Kinetix Comp · Front tire: 20 x 1.50" Schwalbe Marathon Racer
Archived: Headset: 1 1/8" Dahon Fusion+ · Handlebar: Kinetix Pro · Stem: Radius V forged · Seatpost: Kore I-Beam, 34.0mm diameter · Saddle: Kore XC I-Beam · Pedals: Suntour Folding alloy
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
