2027 Commencal Meta HT V3 Signature Pure Black

Original manufacturer specifications including geometry for 4 published sizes.

Share owner experience

Selling this bike? Create a shareable bike record

What Velopedia knows

Model year
2027
Category
Mountain
Original MSRP
$3,800.00
Sizes
S, M, L, XL
Colors
Pure Black, Shiny Finish
Geometry
4 manufacturer sizes · Geometry context
Record coverage
21 preserved details · 8 archived images · original MSRP · preserved geometry
Archive ID
900001418
Campaign

Manufacturer catalog

Published sizes and colors

4 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMLXL

Published colors

Pure BlackShiny Finish

Frameset

Frame ConstructionMETA HT V3: 29''/27'' on S & 29''/29'' on M / L / XL; Alloy 6061, triple butted tubes, T4, T6.
Frame MaterialAluminum
ForkFOX 36 Factory, 150 mm travel; 29", Grip X2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 2 tokens

Drivetrain

ShiftersSHIMANO Deore M6200; 12s
Rear DerailleurSHIMANO Deore M7200; 12s
CranksetSHIMANO Deore M6200, 170 mm crank arms; Chainring : SHIMANO Deore M6200, 32t
Bottom BracketShimano MT801; BSA 68
CassetteSHIMANO Deore M7200; 12s, 10-51t
ChainSHIMANO Deore M6100; 12s
PedalsNo

Brakes

BrakesTRP DHR EVO EXPERT, 4 pistons; Rotors : TRP RS06E 203 mm, 6-bolts

Cockpit & Contact Points

HeadsetACROS ZS56/ZS56; Alloy cups, sealed bearings
HandlebarRIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R35 800 on XL; 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 35 mm rise, Alloy 6061 on XL
StemRIDE ALPHA 40 mm; 40 mm extension, 31.8 mm
SaddleWTB Solano Medium; 142 x 240 mm, Cromo rails
SeatpostKS Rage-I; 31.6 mm, travel: 150 mm on S, 170 mm on M, 190 mm on L/XL

Wheels & Tires

HubsDT SWISS 370; Rear : 32h, sealed bearings, 12 x 148 mm, SHIMANO Microspline - Front : 28h, sealed bearings, 15 x 110 mm
RimsDT SWISS EX511; Rear : 27.5'', 32h, 30 mm inner width rear on S - 29'', 32h, 30 mm inner width front on M / L / XL - Front : 29'', 28h, 30 mm inner width rear on S / M / L / XL
Front TireRear : MAXXIS DHRII - Front : MAXXIS Assegai; Rear : S: 27.5x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ - M / L / XL: 29x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ -Front : 29x2.50WT 3C MaxxTerra, Exo, TR
Rear TireRear : MAXXIS DHRII - Front : MAXXIS Assegai; Rear : S: 27.5x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ - M / L / XL: 29x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ -Front : 29x2.50WT 3C MaxxTerra, Exo, TR

Size-specific frame data

Geometry

4 sizes · 11 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

MeasurementSMLXL
Seat tube380 mm420 mm440 mm460 mm
Effective top tube558 mm603 mm624 mm650 mm
Head tube115 mm120 mm125 mm130 mm
Head-tube angle65.8°64.5°64.5°64.5°
Seat-tube angle76.8°75.5°75.5°75.5°
Chainstay / rear center425 mm430 mm430 mm430 mm
Wheelbase1150 mm1196 mm1218 mm1246 mm
Bottom-bracket drop54.4 mm50 mm50 mm50 mm
Reach410 mm435 mm455 mm480 mm
Stack638 mm649 mm653 mm658 mm
Fork length / axle-to-crown561 mm561 mm561 mm561 mm

Geometry source: Commencal first-party labeled geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.

Geometry tools

Analyze a published size

Choose a size

S geometry

Archive context: Its stack of 638 mm sits toward the taller end. The chainstay of 425 mm sits toward the shorter rear-center end. Its reach of 410 mm sits toward the shorter end.

Compared with 168 distinct mountain geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.
Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry

Parts & serviceability

Find replacement parts

3 top part searches
ChainExact archived part
SHIMANO Deore M6100; 12s Interpreted as Shimano Deore · 12-speed Exact archived model
CassetteMatching configuration
SHIMANO Deore M7200; 12s, 10-51t Interpreted as Shimano Deore · 12-speed Component family — verify exact version
Brake padsVerified replacement
TRP DH-R EVO 4-piston semi-metallic brake pads — ABPD000522 Manufacturer-verified pad family — compare pad shape
More qualified parts (5)
Bottom bracketExact archived part
Shimano MT801; BSA 68 Named archived component — verify dimensions
SaddleExact archived part
WTB Solano Medium; 142 x 240 mm, Cromo rails Named archived component — verify exact version
CranksetQualified part search
SHIMANO Deore M6200, 170 mm crank arms; Chainring : SHIMANO Deore M6200, 32t Component family — verify exact version
Rear derailleurMatching configuration
SHIMANO Deore M7200; 12s Interpreted as Shimano Deore · 12-speed Component family — verify exact version
ShiftersQualified part search
SHIMANO Deore M6200; 12s Interpreted as Shimano Deore · 12-speed Component family — verify exact version

Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.

Campaign

Used-bike inspection

If you’re buying this bike used

Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.

Follow the full used-bike inspection order →
  • FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
  • BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
  • SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
  • DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
  • Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
0 of 20 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2027 Commencal Meta HT V3 Signature Pure Black · Mountain · Published sizes: S, M, L, XL

Archived: Frame: META HT V3: 29''/27'' on S & 29''/29'' on M / L / XL; Alloy 6061, triple butted tubes, T4, T6. · Fork: FOX 36 Factory, 150 mm travel; 29", Grip X2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 2 tokens

Archived: Fork: FOX 36 Factory, 150 mm travel; 29", Grip X2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 2 tokens

Archived: Shifters: SHIMANO Deore M6200; 12s · Rear derailleur: SHIMANO Deore M7200; 12s · Crankset: SHIMANO Deore M6200, 170 mm crank arms; Chainring : SHIMANO Deore M6200, 32t · Bottom bracket: SHIMANO MT801; BSA 68 · Cassette: SHIMANO Deore M7200; 12s, 10-51t · Chain: SHIMANO Deore M6100; 12s

Archived: Brakes: TRP DHR EVO EXPERT, 4 pistons; Rotors : TRP RS06E 203 mm, 6-bolts

Archived: Rims: DT SWISS EX511; Rear : 27.5'', 32h, 30 mm inner width rear on S - 29'', 32h, 30 mm inner width front on M / L / XL - Front : 29'', 28h, 30 mm inner width rear on S / M / L / XL · Hubs: DT SWISS 370; Rear : 32h, sealed bearings, 12 x 148 mm, SHIMANO Microspline - Front : 28h, sealed bearings, 15 x 110 mm

Controls and contact points

Archived: Headset: ACROS ZS56/ZS56; Alloy cups, sealed bearings · Stem: RIDE ALPHA 40 mm; 40 mm extension, 31.8 mm · Seatpost: KS Rage-I; 31.6 mm, travel: 150 mm on S, 170 mm on M, 190 mm on L/XL · Saddle: WTB Solano Medium; 142 x 240 mm, Cromo rails · Pedals: No

Before and during the test ride

Follow the full used-bike inspection order →

Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
