2026 Commencal Meta Power TR Shimano Ride
Original manufacturer specifications including geometry for 8 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Mountain
- Original MSRP
- $5,800.00
- Sizes
- S, M, L, XL
- Colors
- Dark Slate
- Geometry
- 8 manufacturer sizes · Geometry context
- Record coverage
- 24 preserved details · 4 archived images · original MSRP · preserved geometry
- Archive ID
- 900001459
Frameset
| Frame Construction | META POWER TR V4, 140 mm29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
|---|---|
| Frame Material | Aluminum |
| Fork | ROCKSHOX 35 Gold RL, 150 mm travel29'', Motion Control damper, DebonAir, rebound, LSC to lock, (Boost 15 x 110 mm), 44 mm offset, 0 Token |
| Rear Shock | ROCKSHOX Deluxe Select +210 x 55 mm, RT damper, DebonAir, rebound, 2 positions comp (open/firm), 1 Token neg. 4 Token pos |
Drivetrain
| Shifters | SRAM SX Eagle12s |
|---|---|
| Rear Derailleur | SRAM SX Eagle12s |
| Crankset | E13 E*Spec Plus EP8 160 mmChainring : E13 E*Spec Plus 32t, Narrow-Wide, direct mount |
| Cassette | SRAM PG-121012s, 11-50t |
| Chain | SRAM NX Eagle12s |
| Pedals | Ride Alpha CNC |
Brakes
| Brakes | SRAM Guide RE, 4 pistons, steel-backed metal sinteredRotors : SRAM G2 Cleansweep 200mm, 6 holes |
|---|
Cockpit & Contact Points
| Headset | ACROS ZS56 / ZS66Alloy cups, sealed bearings |
|---|---|
| Handlebar | RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL |
| Stem | RIDE ALPHA Freeride 4040 mm extension, 31,8 mm |
| Saddle | FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails |
| Seatpost | KS Ragei 31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remote |
Wheels & Tires
| Hubs | Rear: FORMULA eHL-148S - Front: FORMULA DC-711Rear: 32h, 12 x 148 mm, sealed bearings, e-bike specific, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings |
|---|---|
| Rims | Rear: SPANK Spike Race 33 - Front: SPANK Spike Race 33Rear: 29'', 32h, 28 mm inner width - Front: 29'', 32h, 28 mm inner width |
| Front Tire | Rear: MAXXIS DHR II - Front: MAXXIS DHR IIRear: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready - Front: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready |
| Rear Tire | Rear: MAXXIS DHR II - Front: MAXXIS DHR IIRear: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready - Front: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready |
E-bike System
| Motor | SHIMANO DU-EP800Max. torque: 85N.m, 250W |
|---|---|
| Battery | SHIMANO BT-E8036630Wh internal batterySHIMANO Europlug (CEE 7/7 norm) battery charger(a plug adapter is necessary for customers living in countries using different standards) |
| Display/Remote | SHIMANO SC-EM800LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication) |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S · Low | S · High | M · Low | M · High | L · Low | L · High | XL · Low | XL · High |
|---|---|---|---|---|---|---|---|---|
| Seat tube | 380 mm | 380 mm | 420 mm | 420 mm | 440 mm | 440 mm | 460 mm | 460 mm |
| Effective top tube | 580 mm | 579 mm | 601 mm | 600 mm | 627 mm | 626 mm | 652 mm | 651 mm |
| Head tube | 120 mm | 120 mm | 125 mm | 125 mm | 130 mm | 130 mm | 130 mm | 130 mm |
| Head-tube angle | 64.1° | 64.5° | 64.1° | 64.5° | 64.1° | 64.5° | 64.1° | 64.5° |
| Seat-tube angle | 77.1° | 77.5° | 77.1° | 77.5° | 77.1° | 77.5° | 77.1° | 77.5° |
| Chainstay / rear center | 454 mm | 453 mm | 454 mm | 453 mm | 454 mm | 453 mm | 454 mm | 453 mm |
| Wheelbase | 1231 mm | 1230 mm | 1253 mm | 1252 mm | 1280 mm | 1279 mm | 1305 mm | 1304 mm |
| Bottom-bracket drop | 25.5 mm | 21 mm | 25.5 mm | 21 mm | 25.5 mm | 21 mm | 25.5 mm | 21 mm |
| Reach | 436 mm | 440 mm | 456 mm | 460 mm | 481 mm | 485 mm | 506 mm | 510 mm |
| Stack | 607 mm | 604 mm | 612 mm | 609 mm | 616 mm | 613 mm | 616 mm | 613 mm |
| Fork length / axle-to-crown | 566 mm | 566 mm | 566 mm | 566 mm | 566 mm | 566 mm | 566 mm | 566 mm |
Geometry source: Commencal first-party labeled geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
The manufacturer publishes more than one geometry configuration. Velopedia analyzes each labeled state separately while treating them as one chassis in archive comparisons.
S geometry
Archive context: The chainstay of 454 mm sits toward the longer rear-center end. Its wheelbase of 1231 mm sits toward the longer end. The seat angle of 77.1° sits somewhat steeper than typical.
Compared with 240 distinct mountain geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Archive context: The chainstay of 453 mm sits toward the longer rear-center end. Its wheelbase of 1230 mm sits toward the longer end. Its bottom-bracket drop of 21 mm sits toward the shallower-drop end.
Compared with 240 distinct mountain geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.M geometry
Archive context: The chainstay of 454 mm sits toward the longer rear-center end. Its wheelbase of 1253 mm sits toward the longer end. Its bottom-bracket drop of 25.5 mm sits somewhat shallower than typical.
Compared with 246 distinct mountain geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Archive context: The chainstay of 453 mm sits toward the longer rear-center end. Its bottom-bracket drop of 21 mm sits toward the shallower-drop end. Its wheelbase of 1252 mm sits toward the longer end.
Compared with 246 distinct mountain geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.L geometry
Archive context: The chainstay of 454 mm sits toward the longer rear-center end. Its stack of 616 mm sits toward the lower end. Its wheelbase of 1280 mm sits toward the longer end.
Compared with 239 distinct mountain geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Archive context: The chainstay of 453 mm sits toward the longer rear-center end. Its stack of 613 mm sits toward the lower end. Its bottom-bracket drop of 21 mm sits toward the shallower-drop end.
Compared with 239 distinct mountain geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.XL geometry
Archive context: Its stack of 616 mm sits toward the lower end. The chainstay of 454 mm sits toward the longer rear-center end. Its wheelbase of 1305 mm sits somewhat longer than typical.
Compared with 211 distinct mountain geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Archive context: Its stack of 613 mm sits toward the lower end. The chainstay of 453 mm sits toward the longer rear-center end. Its bottom-bracket drop of 21 mm sits toward the shallower-drop end.
Compared with 211 distinct mountain geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Parts & serviceability
Find replacement parts
More qualified parts (4)
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- E-bike systemConfirm the main battery charges with the correct charger, locks securely into its mount and has no case damage, swelling, corrosion or overheating marks. Power the bike on from cold, test every assist mode and ask for available battery-health and diagnostic records.Check the battery and electronics →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 27 checks based on 7 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Commencal Meta Power TR Shimano Ride · Electric · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: META POWER TR V4, 140 mm29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings · Fork: ROCKSHOX 35 Gold RL, 150 mm travel29'', Motion Control damper, DebonAir, rebound, LSC to lock, (Boost 15 x 110 mm), 44 mm offset, 0 Token
Suspension
Evaluate the suspension →Archived: Fork: ROCKSHOX 35 Gold RL, 150 mm travel29'', Motion Control damper, DebonAir, rebound, LSC to lock, (Boost 15 x 110 mm), 44 mm offset, 0 Token · Rear shock: ROCKSHOX Deluxe Select +210 x 55 mm, RT damper, DebonAir, rebound, 2 positions comp (open/firm), 1 Token neg. 4 Token pos
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM SX Eagle12s · Rear derailleur: SRAM SX Eagle12s · Crankset: E13 E*Spec Plus EP8 160 mmChainring : E13 E*Spec Plus 32t, Narrow-Wide, direct mount · Cassette: SRAM PG-121012s, 11-50t · Chain: SRAM NX Eagle12s
Brakes
Inspect the brakes →Archived: Brakes: SRAM Guide RE, 4 pistons, steel-backed metal sinteredRotors : SRAM G2 Cleansweep 200mm, 6 holes
Wheels and tires
Check wheels and tires →Archived: Rims: Rear: SPANK Spike Race 33 - Front: SPANK Spike Race 33Rear: 29'', 32h, 28 mm inner width - Front: 29'', 32h, 28 mm inner width · Hubs: Rear: FORMULA eHL-148S - Front: FORMULA DC-711Rear: 32h, 12 x 148 mm, sealed bearings, e-bike specific, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings · Front tire: Rear: MAXXIS DHR II - Front: MAXXIS DHR IIRear: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready - Front: 29"x2.4" WT, 3C Maxx Terra, Exo+, Tubeless Ready · Rear tire: Rear: MAXXIS DHR II - Front…
Controls and contact points
Archived: Headset: ACROS ZS56 / ZS66Alloy cups, sealed bearings · Stem: RIDE ALPHA Freeride 4040 mm extension, 31,8 mm · Seatpost: KS Ragei 31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remote · Saddle: FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails · Pedals: RIDE ALPHA CNC
E-bike system
Check the battery and electronics →Archived: Motor: SHIMANO DU-EP800Max. torque: 85N.m, 250W · Battery: SHIMANO BT-E8036630Wh internal batterySHIMANO Europlug (CEE 7/7 norm) battery charger(a plug adapter is necessary for customers living in countries using different standards)
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
