2026 Commencal Meta HT AM Essential Keswick Green
Original manufacturer specifications including geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Mountain
- Original MSRP
- $2,200.00
- Sizes
- S, M, L, XL
- Colors
- Keswick GreenShiny Finish
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 21 preserved details · 4 archived images · original MSRP · preserved geometry
- Archive ID
- 900001409
Frameset
| Frame Construction | 2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XLAlloy 6061, triple butted tubes, T4, T6. |
|---|---|
| Frame Material | Aluminum |
| Fork | ROCKSHOX Yari RC, 150 mm travel29", Motion Control damper, DebonAir, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens |
Drivetrain
| Shifters | SRAM NX Eagle12s |
|---|---|
| Rear Derailleur | SRAM NX Eagle12s |
| Crankset | SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide |
| Bottom Bracket | SRAM BSAThreaded |
| Cassette | SRAM PG-121012s, 11-50t |
| Chain | SRAM NX Eagle12s |
| Pedals | No |
Brakes
| Brakes | SRAM Guide T, 4 pistons, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt |
|---|
Cockpit & Contact Points
| Headset | ACROS ZS44 / ZS56Alloy cups, sealed bearings |
|---|---|
| Handlebar | RIDE ALPHA R20 on S - RIDE ALPHA R27 on M / L / XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL |
| Stem | RIDE ALPHA Freeride 4040 mm extension, 31,8 mm |
| Saddle | FIZIK Terra Alpaca X5145 mm width, S-alloy rails |
| Seatpost | KS Rage-I31.6 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote |
Wheels & Tires
| Hubs | Rear: FORMULA DC-348A - Front: FORMULA DC-711Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm |
|---|---|
| Rims | SPANK Spike Race 33Rear: 27.5'', 32h, 28 mm inner width on S / M - 29'', 32h, 28 mm inner width on L / XL - Front: 29'', 32h, 28 mm inner width on S / M / L / XL |
| Front Tire | Rear: MAXXIS Dissector - Front: MAXXIS DissectorRear: 27.5'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on S / M - 29'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on L / XL - Front: 29" x 2.6", 3C MaxxTerra, EXO+, Tubeless Ready on S / M / L / XL |
| Rear Tire | Rear: MAXXIS Dissector - Front: MAXXIS DissectorRear: 27.5'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on S / M - 29'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on L / XL - Front: 29" x 2.6", 3C MaxxTerra, EXO+, Tubeless Ready on S / M / L / XL |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Seat tube | 380 mm | 420 mm | 465 mm | 490 mm |
| Effective top tube | 582 mm | 604 mm | 630 mm | 653 mm |
| Head tube | 115 mm | 120 mm | 125 mm | 130 mm |
| Head-tube angle | 64° | 64° | 64.5° | 64.5° |
| Seat-tube angle | 74° | 74.5° | 74.5° | 74.5° |
| Chainstay / rear center | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1180 mm | 1202 mm | 1229 mm | 1251 mm |
| Bottom-bracket drop | 30 mm | 30 mm | 40 mm | 40 mm |
| Reach | 405 mm | 425 mm | 450 mm | 475 mm |
| Stack | 638 mm | 643 mm | 647 mm | 646 mm |
| Fork length / axle-to-crown | 561 mm | 561 mm | 561 mm | 561 mm |
Geometry source: Commencal first-party labeled geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
S geometry
Archive context: Its stack of 638 mm sits toward the taller end. Its reach of 405 mm sits toward the shorter end. The seat angle of 74° sits toward the more relaxed end.
Compared with 180 distinct mountain geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.M geometry
Archive context: Its stack of 643 mm sits toward the taller end. Its reach of 425 mm sits toward the shorter end. The seat angle of 74.5° sits toward the more relaxed end.
Compared with 182 distinct mountain geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.L geometry
Archive context: Its stack of 647 mm sits toward the taller end. Its reach of 450 mm sits toward the shorter end. The seat angle of 74.5° sits toward the more relaxed end.
Compared with 178 distinct mountain geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.XL geometry
Archive context: Its reach of 475 mm sits toward the shorter end. The seat angle of 74.5° sits toward the more relaxed end. The chainstay of 432 mm sits toward the shorter rear-center end.
Compared with 153 distinct mountain geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Parts & serviceability
Find replacement parts
More qualified parts (4)
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Commencal Meta HT AM Essential Keswick Green · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: 2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XLAlloy 6061, triple butted tubes, T4, T6. · Fork: ROCKSHOX Yari RC, 150 mm travel29", Motion Control damper, DebonAir, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens
Suspension
Evaluate the suspension →Archived: Fork: ROCKSHOX Yari RC, 150 mm travel29", Motion Control damper, DebonAir, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM NX Eagle12s · Rear derailleur: SRAM NX Eagle12s · Crankset: SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide · Bottom bracket: SRAM BSAThreaded · Cassette: SRAM PG-121012s, 11-50t · Chain: SRAM NX Eagle12s
Brakes
Inspect the brakes →Archived: Brakes: SRAM Guide T, 4 pistons, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt
Wheels and tires
Check wheels and tires →Archived: Rims: SPANK Spike Race 33Rear: 27.5'', 32h, 28 mm inner width on S / M - 29'', 32h, 28 mm inner width on L / XL - Front: 29'', 32h, 28 mm inner width on S / M / L / XL · Hubs: Rear: FORMULA DC-348A - Front: FORMULA DC-711Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm
Controls and contact points
Archived: Headset: ACROS ZS44 / ZS56Alloy cups, sealed bearings · Stem: RIDE ALPHA Freeride 4040 mm extension, 31,8 mm · Seatpost: KS Rage-I31.6 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote · Saddle: FIZIK Terra Alpaca X5145 mm width, S-alloy rails · Pedals: No
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
