Lowest1.14:1
Highest4.50:1
Total range394%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
1995 Co-Motion Java
Original specifications: Shimano Deore XT drivetrain · 700c wheels · 39.4 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #35023- Model year
- 1995
- Category
- Tandem
- Original MSRP
- $2,895.00
- Sizes
- Captain 21"/stoker 19", captain 22"/stoker 20", captain 22.5"/stoker 19", captain 23.5"/stoker 21"
- Colors
- Custom, Dark Green Metallic, Lavender Metallic
- Weight
- 39.4 lb
- Geometry
- Legacy reference
- In this record
- 24 specifications · original MSRP · geometry
Model history 7 other years
Browse other years
Compare side by side
Identification clues
1995 archived details
- Published colors
- Custom, Dark Green Metallic, Lavender Metallic
- Frame
- Tange / True Temper custom mix
- Original equipment
- Shimano Deore XT
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildTange / True Temper custom mix · Shimano Deore XT · 700c wheels
Frameset
| Frame Construction | TIG-welded steel |
|---|---|
| Frame Material | Tange / True Temper custom mix |
| Fork | Co-Motion |
| Fork Material | Tange Tandem chromoly, butted taper gauge, unicrown crown |
Drivetrain
| Component Group | Shimano Deore XT |
|---|---|
| Shifters | Shimano SL-BS64 600 Ultegra bar-end 8-speed |
| Front Derailleur | Shimano Deore XT, bottom-pull/clamp-on 28.6 mm |
| Rear Derailleur | Shimano Deore XT GS |
| Crankset | Specialized Tandem, 32/44/54 teeth |
| Rear Cogs | 8-speed, 12 - 28 teeth |
| Chain | Sachs SC-M55, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Dia-Compe 985c brakes, Dia-Compe 287 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" YST Sealed Tech |
|---|---|
| Handlebar | Profile Hammer |
| Stem | Co-Motion |
| Saddle | Specialized Prolong/Terry |
| Seatpost | SR TCO, 26.8 mm diameter |
Wheels & Tires
| Hubs | Phil Wood tandem |
|---|---|
| Rims | Mavic M3D, 40-hole |
| Spokes | DT stainless steel, 2.0 mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 28c Continental Super Sport Ultra |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 570 mm |
| Head-tube angle | 74° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 438 mm |
| Wheelbase | 1716 mm |
| Fork offset / rake | 38 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
