2026 Cervelo R5 Red AXS, Five Black, 56cm
Used · Fixed price · offers accepted · USD 10750.00
Velopedia Bicycle Archive
2026 Cervelo R5 Red AXS
Original manufacturer specifications including 5.78 kgs published weight, geometry for 6 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Road
- Original MSRP
- $14,400.00
- Sizes
- 48, 51, 54, 56, 58
- Colors
- Five Black/Bronze
- Weight
- 5.78 kgs
- Geometry
- 6 manufacturer sizes · Geometry context
- Record coverage
- 19 preserved details · archived image · original MSRP · preserved geometry
- Archive ID
- 900000016
Frameset
| Frame Construction | Cervélo R5 frame |
|---|---|
| Fork | Cervélo All-Carbon, Tapered R5 Fork |
| Fork Material | Carbon Fiber |
Drivetrain
| Shifters | SRAM Red AXS E1 |
|---|---|
| Front Derailleur | SRAM Red AXS E1 |
| Rear Derailleur | SRAM Red AXS E1 |
| Crankset | SRAM Red AXS E1, 48/35T, DUB, with power meter |
| Bottom Bracket | SRAM DUB Ceramic, BBright |
| Cassette | SRAM Red E1, 10-33T, 12-Speed |
| Chain | SRAM Red E1 |
Brakes
| Brakes | Brake controls: SRAM Red AXS E1; Rotors: SRAM Paceline X Centerlock |
|---|
Cockpit & Contact Points
| Headset | FSA SL IS2 1-1/4, 45° x 45° / 1-1/2, 36° x 45° |
|---|---|
| Handlebar | Cervélo HB18 Carbon |
| Saddle | Prologo Nago R4 PAS Nack Lightweight |
| Seatpost | Cervélo SP33 Carbon |
Wheels & Tires
| Wheels | Front: Reserve 34TA SL, DT Swiss 180, 12x100mm, 24H, centerlock, tubeless compatible; Rear: Reserve 37TA SL, DT Swiss 180, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible |
|---|---|
| Front Tire | Vittoria Corsa Pro Speed TLR G2.0 700x26c |
| Rear Tire | Vittoria Corsa Pro Speed TLR G2.0 700x26c |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Top tube | 506 mm | 526 mm | 545 mm | 565 mm | 581 mm | 595 mm |
| Head tube | 89.6 mm | 109.3 mm | 132 mm | 156 mm | 182.8 mm | 203.7 mm |
| Head-tube angle | 71° | 72° | 73° | 73° | 73° | 73° |
| Seat-tube angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Chainstay / rear center | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 976.8 mm | 977.6 mm | 978 mm | 992.8 mm | 1010.3 mm | 1024.5 mm |
| Bottom-bracket drop | 76.5 mm | 76.5 mm | 74 mm | 74 mm | 71.5 mm | 71.5 mm |
| Reach | 368.7 mm | 376.5 mm | 383.3 mm | 391.1 mm | 400.3 mm | 408.3 mm |
| Stack | 496.1 mm | 520.2 mm | 544.6 mm | 567.5 mm | 590.7 mm | 610.7 mm |
| Standover height | 699.7 mm | 731 mm | 757.4 mm | 779.1 mm | 803.4 mm | 822.2 mm |
| Fork offset / rake | 57.5 mm | 51.5 mm | 45.5 mm | 45.5 mm | 45.5 mm | 45.5 mm |
| Front center | 579.1 mm | 579.9 mm | 579.5 mm | 594.2 mm | 610.8 mm | 624.8 mm |
| Trail | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
48 geometry
Archive context: Its reach of 368.7 mm sits toward the shorter end. Its trail of 57.3 mm sits toward the lower-trail end. Its stack of 496.1 mm sits toward the lower end.
Compared with 88 distinct road geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 48 geometry 51 geometry
Archive context: Its trail of 57.3 mm sits toward the lower-trail end. Its bottom-bracket drop of 76.5 mm sits toward the deeper-drop end. Its wheelbase of 977.6 mm sits somewhat shorter than typical.
Compared with 88 distinct road geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 51 geometry 54 geometry
Archive context: Its wheelbase of 978 mm sits toward the shorter end. Its trail of 57.3 mm sits toward the lower-trail end. The head angle of 73° sits toward the steeper end.
Compared with 88 distinct road geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 54 geometry 56 geometry
Archive context: The seat angle of 73° sits toward the more relaxed end. Its wheelbase of 992.8 mm sits toward the shorter end. Its bottom-bracket drop of 74 mm sits somewhat deeper than typical.
Compared with 77 distinct road geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 56 geometry 58 geometry
Archive context: The chainstay of 410 mm sits somewhat shorter than typical. The seat angle of 73° sits somewhat more relaxed than typical. Its wheelbase of 1010.3 mm sits somewhat shorter than typical.
Compared with 63 distinct road geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 58 geometry 61 geometry
Archive context: Its stack of 610.7 mm sits somewhat lower than typical. The chainstay of 410 mm sits somewhat shorter than typical. The seat angle of 73° sits somewhat more relaxed than typical.
Compared with 39 distinct road geometries in the XXL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 61 geometry Parts & serviceability
Find replacement parts
SRAM Red E1
Interpreted as SRAM RED · 12-speed Named component · published drivetrain speed — verify exact version
SRAM Red E1, 10-33T, 12-Speed
Interpreted as SRAM RED · 12-speed Component family — verify exact version
Vittoria Corsa Pro Speed TLR G2.0 700x26c
Named tire and published size
More qualified parts (6)
SRAM DUB Ceramic, BBright
Named archived component — verify dimensions
Prologo Nago R4 PAS Nack Lightweight
Named archived component — verify exact version
SRAM Red AXS E1, 48/35T, DUB, with power meter
Component family — verify exact version
SRAM Red AXS E1
Interpreted as SRAM RED · 12-speed · electronic Component family — verify exact version
SRAM Red AXS E1
Interpreted as SRAM RED · 12-speed · electronic Component family — verify exact version
SRAM Red AXS E1
Interpreted as SRAM RED · 12-speed · electronic Component family — verify exact version
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the complete frame and fork in bright light for cracks, dents, distortion, corrosion, impact marks, suspicious paint differences or signs of repair. Check the head tube, bottom-bracket area, dropouts, joints and clamped surfaces especially closely.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainConfirm every shift-system battery charges, every shift control works and the derailleur moves cleanly across the cassette. Make sure the matching shift-system charger is included, then measure chain wear and inspect the cassette teeth.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Cervelo R5 Red AXS · Road · Published sizes: 48, 51, 54, 56, 58
Frame and fork
Inspect the frame and fork →Archived: Frame: Cervélo R5 frame · Fork: Cervélo All-Carbon, Tapered R5 Fork · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM Red AXS E1 · Front derailleur: SRAM Red AXS E1 · Rear derailleur: SRAM Red AXS E1 · Crankset: SRAM Red AXS E1, 48/35T, DUB, with power meter · Bottom bracket: SRAM DUB Ceramic, BBright · Cassette: SRAM Red E1, 10-33T, 12-Speed · Chain: SRAM Red E1
Brakes
Inspect the brakes →Archived: Brakes: Brake controls: SRAM Red AXS E1; Rotors: SRAM Paceline X Centerlock
Wheels and tires
Check wheels and tires →Archived: Wheels: Front: Reserve 34TA SL, DT Swiss 180, 12x100mm, 24H, centerlock, tubeless compatible; Rear: Reserve 37TA SL, DT Swiss 180, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible · Front tire: Vittoria Corsa Pro Speed TLR G2.0 700x26c · Rear tire: Vittoria Corsa Pro Speed TLR G2.0 700x26c
Controls and contact points
Archived: Headset: FSA SL IS2 1-1/4, 45° x 45° / 1-1/2, 36° x 45° · Handlebar: Cervélo HB18 Carbon · Seatpost: Cervélo SP33 Carbon · Saddle: Prologo Nago R4 PAS Nack Lightweight
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
