2025 Canyon Ultimate CF SLX Frameset
Original manufacturer specifications including 27.5; 700C wheels, 5.34 lb published weight, geometry for 8 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2025
- Category
- Road
- Original MSRP
- $2,499.00
- Sizes
- 3XS, S, M, L, XXL, XXS, XS, XL
- Colors
- Frozen Black, Iced Berry
- Weight
- 5.34 lb
- Geometry
- 8 manufacturer sizes · Geometry context
- Record coverage
- 7 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001392
Frameset
| Frame Construction | Canyon Ultimate CF SLX |
|---|---|
| Frame Material | Carbon (CF) |
| Fork | Canyon FK0104 CF |
| Fork Material | Carbon |
Cockpit & Contact Points
| Seatpost | Canyon SP0055 |
|---|
Wheels & Tires
| Wheel Size | 27.5; 700C |
|---|
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 3XS | S | M | L | XXL | 2XS | XS | XL |
|---|---|---|---|---|---|---|---|---|
| Seat tube | 390 mm | 480 mm | 510 mm | 540 mm | 600 mm | 420 mm | 450 mm | 570 mm |
| Effective top tube | 497 mm | 546 mm | 555 mm | 569 mm | 609 mm | 516 mm | 529 mm | 594 mm |
| Head tube | 104 mm | 121 mm | 142 mm | 162 mm | 206 mm | 88 mm | 107 mm | 188 mm |
| Head-tube angle | 70.2° | 72.8° | 73.25° | 73.3° | 73.8° | 70° | 71.2° | 73.5° |
| Seat-tube angle | 73.5° | 73.9° | 73.9° | 73.9° | 73.9° | 73.5° | 73.5° | 73.5° |
| Chainstay / rear center | 405 mm | 410 mm | 410 mm | 413 mm | 415 mm | 410 mm | 410 mm | 415 mm |
| Wheelbase | 958 mm | 982 mm | 988 mm | 1003 mm | 1042 mm | 975 mm | 979 mm | 1029 mm |
| Bottom-bracket drop | 60 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Reach | 358 mm | 390 mm | 393 mm | 401 mm | 429 mm | 372 mm | 378 mm | 419 mm |
| Stack | 483 mm | 539 mm | 560 mm | 580 mm | 624 mm | 498 mm | 520 mm | 606 mm |
| Wheel size | 27.5 | 700C | 700C | 700C | 700C | 700C | 700C | 700C |
Geometry source: Canyon first-party ProductGroup geometry ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
3XS geometry
Archive context: Its wheelbase of 958 mm sits toward the shorter end. Its stack of 483 mm sits toward the lower end. The chainstay of 405 mm sits toward the shorter rear-center end.
Compared with 34 distinct road geometries in the XXS-equivalent size cohort from model years 2023–2027 in the Velopedia archive.S geometry
Archive context: The head angle of 72.8° sits toward the steeper end. Its reach of 390 mm sits toward the longer end. The seat angle of 73.9° sits somewhat more relaxed than typical.
Compared with 88 distinct road geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.M geometry
Archive context: The head angle of 73.3° sits toward the steeper end. Its reach of 393 mm sits toward the longer end. The chainstay of 410 mm sits somewhat shorter than typical.
Compared with 89 distinct road geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.L geometry
Archive context: The head angle of 73.3° sits toward the steeper end. Its reach of 401 mm sits somewhat longer than typical. The seat angle of 73.9° sits somewhat steeper than typical.
Compared with 77 distinct road geometries in the Large-equivalent size cohort from model years 2023–2027 in the Velopedia archive.XXL geometry
Archive context: Its reach of 429 mm sits toward the longer end. The seat angle of 73.9° sits toward the steeper end. The head angle of 73.8° sits toward the steeper end.
Compared with 39 distinct road geometries in the XXL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.2XS geometry
Archive context: The seat angle of 73.5° sits toward the more relaxed end. The head angle of 70° sits toward the slacker end. Its stack of 498 mm sits somewhat lower than typical.
Compared with 34 distinct road geometries in the XXS-equivalent size cohort from model years 2023–2027 in the Velopedia archive.XS geometry
Archive context: The seat angle of 73.5° sits toward the more relaxed end. Its reach of 378 mm sits somewhat longer than typical. The head angle of 71.2° sits somewhat steeper than typical.
Compared with 64 distinct road geometries in the XS-equivalent size cohort from model years 2023–2027 in the Velopedia archive.XL geometry
Archive context: The head angle of 73.5° sits toward the steeper end. Its reach of 419 mm sits toward the longer end. Its bottom-bracket drop of 73 mm sits somewhat deeper than typical.
Compared with 63 distinct road geometries in the XL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Used-frameset inspection
If you’re buying this frameset used
Before buying: confirm the serial number and exact model, inspect frame and fork alignment, and inventory every included axle, hanger, clamp, headset part, cable guide and proprietary fitting.
Inspect the frame and fork →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- Included hardwareInventory every axle, hanger, clamp, headset part, cable guide, frame plug and proprietary fitting included with the frameset. Confirm replacement availability before treating a missing small part as insignificant.
- AlignmentSight along the frame and fork from several directions. Confirm that the fork, rear dropouts, head tube and other visible interfaces appear straight; professional measurement is appropriate when alignment cannot be established visually.
Used-frameset inspection checklist 14 universal checks for a record with limited component data Open checklistClose checklist
The archived record does not contain enough component detail for a fully specification-informed frameset checklist. Use these universal checks on the frameset in front of you, inventory every included part and confirm exact interfaces before choosing components.
Identity and fit
Follow the full used-bike inspection order →Archived: 2025 Canyon Ultimate CF SLX Frameset · Road · Published sizes: 3XS, S, M, L, XXL, XXS, XS, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Canyon Ultimate CF SLX · Fork: Canyon FK0104 CF · Carbon
Alignment
Inspect the frame and fork →Frame interfaces
Inspect the bottom bracket and shell →Before accepting the frameset
Inspect the frame and fork →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
