Velopedia Bicycle Archive
2025 Canyon Sender CFR Team
Original manufacturer specifications including 29"/27.5 wheels, 39.51 lb published weight, geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2025
- Category
- Mountain
- Original MSRP
- $7,399.00
- Sizes
- S, M, L, XL
- Colors
- CFR Mint
- Weight
- 39.51 lb
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 20 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001401
Frameset
| Frame Construction | Canyon Sender CFR |
|---|---|
| Frame Material | Carbon (CFR) |
| Fork | RockShox BoXXer Ultimate |
| Rear Shock | RockShox Vivid COIL DH |
Drivetrain
| Shifters | SRAM X01 DH |
|---|---|
| Rear Derailleur | SRAM X01 DH |
| Crankset | SRAM X01 DH |
| Bottom Bracket | SRAM BSA DUB |
| Cassette | SRAM PG720 |
| Chain | SRAM PC 1110 11S |
Brakes
| Brakes | SRAM Maven Silver Stealth |
|---|
Cockpit & Contact Points
| Handlebar | Canyon G5 |
|---|---|
| Stem | Canyon G5 |
| Saddle | Ergon SMD20 |
| Seatpost | G5 Seatpost |
Wheels & Tires
| Wheels | DT Swiss FR1500 |
|---|---|
| Front Tire | Maxxis Assegai MaxxGrip DH |
| Rear Tire | Maxxis Minion DHR II 2.4" |
| Wheel Size | 29"/27.5 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | XL | M | L |
|---|---|---|---|---|
| Seat tube | 400 mm | 440 mm | 400 mm | 420 mm |
| Effective top tube | 570 mm | 654 mm | 596 mm | 630 mm |
| Head tube | 100 mm | 115 mm | 105 mm | 110 mm |
| Head-tube angle | 63° | 63° | 63° | 63° |
| Seat-tube angle | 78.5° | 78° | 78.5° | 78° |
| Chainstay / rear center | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1246 mm | 1328 mm | 1273 mm | 1303 mm |
| Bottom-bracket drop | 24 mm | 24 mm | 24 mm | 24 mm |
| Reach | 443 mm | 518 mm | 468 mm | 495 mm |
| Stack | 626 mm | 639 mm | 630 mm | 635 mm |
| Standover height | 753 mm | 759 mm | 756 mm | 754 mm |
| Crank length | 165 mm | 165 mm | 165 mm | 165 mm |
| Stem length | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheel size | 29"/27.5 | 29"/27.5 | 29"/27.5 | 29"/27.5 |
Geometry source: Canyon first-party ProductGroup geometry ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
S geometry
Archive context: Its wheelbase of 1246 mm sits toward the longer end. The head angle of 63° sits toward the slacker end. The seat angle of 78.5° sits toward the steeper end.
Compared with 195 distinct mountain geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry XL geometry
Archive context: Its wheelbase of 1328 mm sits toward the longer end. The head angle of 63° sits toward the slacker end. The seat angle of 78° sits toward the steeper end.
Compared with 166 distinct mountain geometries in the XL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry M geometry
Archive context: Its wheelbase of 1273 mm sits toward the longer end. The seat angle of 78.5° sits toward the steeper end. The head angle of 63° sits toward the slacker end.
Compared with 199 distinct mountain geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: Its wheelbase of 1303 mm sits toward the longer end. The seat angle of 78° sits toward the steeper end. The head angle of 63° sits toward the slacker end.
Compared with 193 distinct mountain geometries in the Large-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry Parts & serviceability
Find replacement parts
SRAM BSA DUB
Named archived component — verify dimensions
Ergon SMD20
Named archived component — verify exact version
SRAM X01 DH
Named archived component — verify exact version
More qualified parts (3)
SRAM X01 DH
Interpreted as SRAM X01 DH · 11-speed · mechanical Named component · published drivetrain speed — verify exact version
SRAM X01 DH
Interpreted as SRAM X01 DH · 11-speed · mechanical Named component · published drivetrain speed — verify exact version
DT Swiss FR1500
Named archived component — verify dimensions
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 22 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2025 Canyon Sender CFR Team · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Canyon Sender CFR · Fork: RockShox BoXXer Ultimate
Suspension
Evaluate the suspension →Archived: Fork: RockShox BoXXer Ultimate · Rear shock: RockShox Vivid COIL DH
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM X01 DH · Rear derailleur: SRAM X01 DH · Crankset: SRAM X01 DH · Bottom bracket: SRAM BSA DUB · Cassette: SRAM PG720 · Chain: SRAM PC 1110 11s
Brakes
Inspect the brakes →Archived: Brakes: SRAM Maven Silver Stealth
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29"/27.5 · Wheels: DT Swiss FR1500 · Front tire: Maxxis Assegai MaxxGrip DH · Rear tire: Maxxis Minion DHR II 2.4"
Controls and contact points
Archived: Handlebar: Canyon G5 · Stem: Canyon G5 · Seatpost: G5 Seatpost · Saddle: Ergon SMD20
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery
Recently checked marketplace data
Market Snapshot
Velopedia did not find a close used eBay listing in the latest snapshot. New and used listings remain separate.
Evidence standard
Fixed-price and Best Offer item prices only
Shipping and tax excluded
Active asks, not completed sales
No close current matches found. Velopedia did not find an eBay listing confident enough to include in the latest snapshot.
Listings shown have not passed their eBay-supplied end time. Velopedia rechecks matched bicycles on a protected weekly cycle; availability can still change between checks. Price calculations use active fixed-price and Best Offer item prices before shipping and tax. Auction bids, auction-only prices, classified ads, lower-confidence Review candidates and ended listings are excluded. These observations are not completed-sale prices, a certified appraisal or a guarantee of value.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
