2020 Cannondale Bad Boy 1

Archived: 2020 Cannondale Bad Boy 1 · City & Commuter · Published sizes: MD; SM; XL; LG

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: SmartForm C1 Alloy, integrated Urban Armor bumper, BSA, 1-1/8" headtube, sliding dropout · Fork: Lefty LightPipe rigid, integrated SuperNova LED lightstrip, USB rechargeable battery, 1-1/8" steerer

• Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.

Archived: Fork: Lefty LightPipe rigid, integrated SuperNova LED lightstrip, USB rechargeable battery, 1-1/8" steerer

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Shifters: Shimano Alfine Rapidfire, 8-speed · Rear derailleur: Shimano Alfine 8-speed internal gear rear hub · Crankset: Gates S150, Gates Belt Drive CDX sprocket 46T · Bottom bracket: Thun Zumba · Rear cogs: Gates, CDX, 22T · Chain: Gates Carbon Drive, CDX Centertrack, 113T

• Shift the hub through its complete range using the correct procedure. Check cable or electronic actuation, axle security, hub-shell condition and any sign of lubricant leakage.
• Inspect the belt teeth and edges for damage, verify alignment and tension, and check that any frame split or belt-tensioning hardware is secure.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Brakes Shimano MT400 hydraulic disc, 160/160mm RT26/RT30 rotors Brake Levers Shimano MT401 hydraulic disc

• Squeeze each lever firmly. It should feel consistent and return cleanly. Check levers, hoses and calipers for fluid, inspect pad thickness and contamination, and examine rotors for wear or bending.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 27.5 · Rims: Cannondale, double wall w/eyelets, 32h · Hubs: (F) Lefty 50 front / (R) Shimano Alfine 8-speed internal rear · Front tire: WTB Byway, 650bx40c · Rear tire: WTB Byway, 650bx40c

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.

Archived: Headset: FSA Cartridge Bearing · Handlebar: Cannondale Riser, 6061 Alloy, 18mm rise, 8° back, 4° up, 680mm · Stem: Bad Boy Si, integrated sandwich stem, 65mm · Seatpost: LightSkin w/ integrated rear LED light, 31.6, USB Rechargeable · Saddle: Fabric Scoop Radius Elite, cro-mo rails

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
