Lowest1.29:1
Highest3.83:1
Total range298%
Velopedia Bicycle Archive
At a glance
Archive #2028599- Model year
- 2012
- Category
- Gravel & Cyclocross
- Sizes
- 44cm, 48cm, 51cm, 54cm, 56cm, 58cm, 61cm
- Colors
- Matte Black
- In this record
- 18 specifications · 2 archived images
Original buildOptimized 6061 Alloy
Frameset
| Frame Material | Optimized 6061 Alloy |
|---|---|
| Fork | Cannondale Ultra X carbon/alum |
Drivetrain
| Shifters | Shimano Tiagra STI 10spd |
|---|---|
| Front Derailleur | Shimano Tiagra |
| Rear Derailleur | Shimano Tiagra 10spd |
| Crankset | FSA SL-K Omega 46/36t |
| Bottom Bracket | Bb30 |
| Cassette | Shimano Tiagra 10spd 12-28t |
| Chain | KMC X-10 |
| Pedals | not included |
Brakes
| Brakes | Tektro CR-520 wide canti |
|---|
Cockpit & Contact Points
| Headset | Caadx Si |
|---|---|
| Handlebar | Cannondale C4 Compact |
| Stem | Cannondale C4 |
| Saddle | Cannondale Stage |
| Seatpost | Cannondale C4 Alloy |
Wheels & Tires
| Rims | Maddux DRX 6000 |
|---|---|
| Front Tire | Schwalbe Sammy Slick 700x35c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Schwalbe Sammy Slick 700x35c
Retailer offers
Vittoria Randonneur Reflect Tire Black, 700x35
700x35c
Replacement option
Other replacement options (1)
Challenge Strada Pro Tubeless Tire Black, 700x35
700x35c
Replacement option
Schwalbe Sammy Slick on eBaySponsored links
Shimano Tiagra 10spd 12-28t
More parts (4)Fewer parts
FSA SL-K Omega 46/36t
Shimano Tiagra
Shimano Tiagra 10spd
Shimano Tiagra STI 10spd
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Schwalbe Sammy Slick 700x35c
- Drivetrain
- 10-speed
- Bottom bracket / shell
- BB30
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Optimized 6061 Alloy · Fork: Cannondale Ultra X carbon/alum
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano Tiagra STI 10spd · Front derailleur: Shimano Tiagra · Rear derailleur: Shimano Tiagra 10spd · Crankset: FSA SL-K Omega 46/36t · Bottom bracket: BB30 · Cassette: Shimano Tiagra 10spd 12-28t · Chain: KMC X-10
Brakes
Inspect the brakes →Archived: Brakes: Tektro CR-520 wide canti
Wheels and tires
Check wheels and tires →Archived: Rims: Maddux DRX 6000 · Front tire: Schwalbe Sammy Slick 700x35c
Controls and contact points
Archived: Headset: CAADX SI · Handlebar: Cannondale C4 Compact · Stem: Cannondale C4 · Seatpost: Cannondale C4 Alloy · Saddle: Cannondale Stage · Pedals: not included
