2002 Cannondale MT2000

Original specifications: Shimano XTR · 9-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #36989
Model year
2002
Category
Tandem
Original MSRP
$4,182.99
Sizes
L/M, L/S, M/S, XL/M, XL/S
Colors
Tangelo
In this record
26 specifications · archived image · original MSRP
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2002 archived details

Published colors
Tangelo
Frame
6061 T6 aluminum
Original equipment
Tandem Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build6061 T6 aluminum · Tandem Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

L/ML/SM/SXL/MXL/S

Published colors

Tangelo

Frameset

Frame ConstructionTIG-welded
Frame Material6061 T6 aluminum
ForkCannondale Fatty R
Fork MaterialAluminum, unicrown crown

Drivetrain

Component GroupTandem Mix
ShiftersShimano Deore XT RapidFire SL
Front DerailleurShimano XT
Rear DerailleurShimano XTR SGS
CranksetCannondale Tarantula Tandem, 22/32/44 teeth
Bottom BracketShimano BB-6500, 109.5mm spindle
Rear Cogs9-speed, 11 - 34 teeth
Chain1/2 x 3/32"
PedalsNot included

Brakes

BrakesMagura Gustav M Disc brakes, Magura Gustav M levers

Cockpit & Contact Points

Headset1 1/8" threadless Cane Creek S-2
HandlebarSyntace VRO
Handlebar ExtensionsNot included
StemSyntace VRO
SaddleCannondale Expert/Selle Royal Look-In
SeatpostCannondale Competition/Supension

Wheels & Tires

HubsDT Tandem Disc
RimsSun Rims Rhyno Lite, 40-hole
SpokesDT stainless steel, 14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.10" Continental Explorer Pro
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build44/32/22T · 11–34T · 9-speed
Lowest0.65:1 Highest4.00:1 Total range618%
Estimated speed At 90 RPM Lowest gear4.5 mph Highest gear28.1 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
26 x 2.10" Continental Explorer Pro
Bottom bracket · Original
Shimano BB-6500

109.5mm spindle

Front derailleur · Original
Shimano XT
More parts (2)Fewer parts
Rear derailleur · Original
Shimano XTR SGS
Shifters · Original
Shimano Deore XT RapidFire SL

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" Continental Explorer Pro
Drivetrain
9-speed
Bottom bracket / shell
Shimano BB-6500, 109.5mm spindle
Campaign
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Cannondale Fatty R · Aluminum, unicrown crown

Archived: Group: Tandem Mix · Shifters: Shimano Deore XT RapidFire SL · Front derailleur: Shimano XT · Rear derailleur: Shimano XTR SGS · Crankset: Cannondale Tarantula Tandem, 22/32/44 teeth · Bottom bracket: Shimano BB-6500, 109.5mm spindle · Rear cogs: 9-speed, 11 - 34 teeth · Chain: 1/2 x 3/32"

Archived: Brakes: Magura Gustav M Disc brakes, Magura Gustav M levers

Archived: Wheel size: 26" wheels · Rims: Sun Rims Rhyno Lite, 40-hole · Hubs: DT Tandem Disc · Front tire: 26 x 2.10" Continental Explorer Pro

Controls and contact points

Archived: Headset: 1 1/8" threadless Cane Creek S-2 · Handlebar: Syntace VRO · Stem: Syntace VRO · Seatpost: Cannondale Competition/Supension · Saddle: Cannondale Expert/Selle Royal Look-In · Pedals: Not included
