1998 Cannondale Multisport 600

Original specifications: Shimano RX-100 drivetrain · 650c wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #71155
Model year
1998
Category
Road
Original MSRP
$1,300.99
Sizes
48 cm, 50 cm, 52 cm, 54 cm, 56 cm, 58 cm, 60 cm, 63 cm
Colors
Grape juice pearl, Split Pea
Geometry
Legacy reference
In this record
27 specifications · archived image · original MSRP · geometry
Model history 1 other year

Browse other years

Compare side by side

Identification clues

1998 archived details

Published colors
Grape juice pearl, Split Pea
Frame
6061 T6 aluminum
Original equipment
Shimano RX-100

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061 T6 aluminum · Shimano RX-100 · 650c wheels

Manufacturer catalog

Published sizes and colors

8 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

48 cm50 cm52 cm54 cm56 cm58 cm60 cm63 cm

Published colors

Grape juice pearlSplit Pea

Frameset

Frame ConstructionTIG-welded
Frame Material6061 T6 aluminum
ForkCannondale Air Foil
Fork MaterialAero

Drivetrain

Component GroupShimano RX-100
ShiftersShimano RX-100 STI Dual Control
Front DerailleurShimano RX-100 top-swing, bottom-pull/braze-on
Rear DerailleurShimano RX-100 GS
CranksetShimano RX-100, 39/53 teeth
Bottom BracketShimano BB-UN52
BB Shell Width68mm English
Rear Cogs8-speed, 11 - 21 teeth
ChainShimano Hyperglide, 1/2 x 3/32"
PedalsLook PM-137

Brakes

BrakesShimano RX-100 Dual Pivot brakes, Shimano RX-100 levers

Cockpit & Contact Points

Headset1" Tange-Seiki SE-II
HandlebarCoda 700R
Handlebar ExtensionsProfile Century ZB
StemAlico YC chromoly
SaddleCODA 900M, tubular chromoly rails
SeatpostKalloy SP-257, 27.2mm diameter

Wheels & Tires

HubsShimano RX-100
RimsMavic CXP 12, 32-hole
SpokesDT stainless steel, 1.8mm straight gauge
Spoke NipplesBrass nipples
Front Tire650 x 23c Continental Super Sport 100
Wheel Size650c wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube570 mm
Head-tube angle72°
Seat-tube angle75°
Chainstay / rear center380 mm
Wheelbase999 mm
Fork offset / rake35 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes53/39T · 11–21T · 8-speed
Lowest1.86:1 Highest4.82:1 Total range259%
Estimated speed At 90 RPM Lowest gear12.1 mph Highest gear31.3 mph

Uses front tire 650C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Seatpost · Original
Kalloy SP-257

27.2mm diameter

Front tire · Original
650 x 23c Continental Super Sport 100 Replacement search: 650cx23 bicycle tire Before ordering: Check rim type and tire clearance.
Bottom bracket · Original
Shimano BB-UN52
More parts (3)Fewer parts
Rear derailleur · Original
Shimano RX-100 GS
Shifters · Original
Shimano RX-100 STI Dual Control
Rims · Original
Mavic CXP 12

32-hole

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
650 x 23c Continental Super Sport 100
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano BB-UN52 · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Cannondale Air Foil · Aero

Archived: Group: Shimano RX-100 · Shifters: Shimano RX-100 STI Dual Control · Front derailleur: Shimano RX-100 top-swing, bottom-pull/braze-on · Rear derailleur: Shimano RX-100 GS · Crankset: Shimano RX-100, 39/53 teeth · Bottom bracket: Shimano BB-UN52 · Rear cogs: 8-speed, 11 - 21 teeth · Chain: Shimano Hyperglide, 1/2 x 3/32"

Archived: Brakes: Shimano RX-100 Dual Pivot brakes, Shimano RX-100 levers

Archived: Wheel size: 650c wheels · Rims: Mavic CXP 12, 32-hole · Hubs: Shimano RX-100 · Front tire: 650 x 23c Continental Super Sport 100

Controls and contact points

Archived: Headset: 1" Tange-Seiki SE-II · Handlebar: CODA 700R · Stem: Alico YC chromoly · Seatpost: Kalloy SP-257, 27.2mm diameter · Saddle: CODA 900M, tubular chromoly rails · Pedals: Look PM-137
