Lowest1.20:1
Highest4.33:1
Total range361%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Brodie Ronin
Original specifications: Shimano Tiagra · 9-speed rear derailleur · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #21455- Model year
- 2010
- Category
- Gravel & Cyclocross
- Original MSRP
- $1,449.00
- Sizes
- 48cm, 51cm, 54cm, 57cm, 60cm
- Colors
- Metallic RootBeer
- In this record
- 24 specifications · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- Metallic RootBeer
- Frame
- Brodie DB Cromoly
- Original equipment
- Shimano Tiagra Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildBrodie DB Cromoly · Shimano Tiagra Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Brodie DB Cromoly |
| Fork | Broadie Cromo Road Disc |
| Fork Material | Chromoly, unicrown crown |
Drivetrain
| Component Group | Shimano Tiagra Mix |
|---|---|
| Shifters | Shimano Tiagra STI Dual Control |
| Front Derailleur | Shimano Tiagra, clamp-on |
| Rear Derailleur | Shimano Tiagra |
| Crankset | Shimano Tiaga, 30/39/52 teeth |
| Bottom Bracket | Shimano |
| Cassette | Shimano HG50 |
| Rear Cogs | 9-speed, 12 - 25 teeth |
| Pedals | Shimano SPD |
Brakes
| Brakes | Avid BB Road Mechanical w/ 6" Rotor brakes, Shimano Tiagra STI Dual Control levers |
|---|
Cockpit & Contact Points
| Handlebar | Brodie Compact Road |
|---|---|
| Handlebar Extensions | Not included |
| Stem | Brodie Compact Road, 31.8 |
| Saddle | WTB SST |
| Seatpost | Brodie Road, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Formula, Rear: Shimano M475 |
|---|---|
| Rims | Alex TD17, 32-hole |
| Spokes | Kore stainless steel |
| Front Tire | 700 x 28c Kenda K-176 |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Brodie Road
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
Shimano HG50
700 x 28c Kenda K-176
Replacement search: 700cx28 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (7)Fewer parts
Shimano SPD
WTB SST
Shimano Tiaga
30/39/52 teeth
Shimano Tiagra
clamp-on
Shimano Tiagra
Shimano Tiagra STI Dual Control
Alex TD17
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Kenda K-176
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Shimano
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Broadie Cromo Road Disc · Chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Tiagra Mix · Shifters: Shimano Tiagra STI Dual Control · Front derailleur: Shimano Tiagra, clamp-on · Rear derailleur: Shimano Tiagra · Crankset: Shimano Tiaga, 30/39/52 teeth · Bottom bracket: Shimano · Cassette: Shimano HG50 · Rear cogs: 9-speed, 12 - 25 teeth
Brakes
Inspect the brakes →Archived: Brakes: Avid BB Road Mechanical w/ 6" Rotor brakes, Shimano Tiagra STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex TD17, 32-hole · Hubs: Front: Formula, Rear: Shimano M475 · Front tire: 700 x 28c Kenda K-176
Controls and contact points
Archived: Handlebar: Brodie Compact Road · Stem: Brodie Compact Road, 31.8 · Seatpost: Brodie Road, 27.2mm diameter · Saddle: WTB SST · Pedals: Shimano SPD
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Same model · another year
Ronin
Same model · another year
Ronin
- Frame
- Brodie DB Cromoly
- Groupset
- Cyclocross Mix
Same brand and year
Romax
- Frame
- Brodie Select Butted Scandium
- Groupset
- Cyclocross Mix
Same brand and year
Romax B
Same category and period
Felt F15X
- Frame
- Double butted Aluminum
- Groupset
- Shimano 105 Mix
Same category and period
Norco CCX 1
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
