Lowest0.69:1
Highest2.91:1
Total range423%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.35; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Brodie Hellion
Original specifications: SRAM X5 · 8-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #21443- Model year
- 2010
- Category
- Mountain
- Original MSRP
- $849.00
- Sizes
- XS, S, M, L, XL
- Colors
- White
- In this record
- 24 specifications · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- White
- Frame
- 6061 Butted Aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 Butted Aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 Butted Aluminum |
| Fork | Suntour Duro DJ, 130mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | SRAM X.4 trigger |
| Front Derailleur | SRAM 3.0 |
| Rear Derailleur | SRAM X.5 |
| Crankset | Truvativ Ruktion, 22/32+bash teeth |
| Bottom Bracket | TruVativ |
| Cassette | Shimano HG-40 |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Pedals | Wellgo DH Flats |
Brakes
| Brakes | Avid BB-5 Mechanical w/7" rotor brakes, Avid FR-5 front/Avid FR- 5 rear levers |
|---|
Cockpit & Contact Points
| Handlebar | Brodie Lo Rise |
|---|---|
| Handlebar Extensions | Not included |
| Stem | Brodie 4-bolt |
| Saddle | Brodie FR |
| Seatpost | Brodie 2-bolt, 31.6mm diameter |
Wheels & Tires
| Hubs | Front: Formula, Rear: Shimano M475 |
|---|---|
| Rims | Front: Alex SX-44, Rear: Ales SX-44, 32-hole |
| Spokes | Stainless steel |
| Front Tire | 26 x 2.35" Kenda Kinetics |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Brodie 2-bolt
31.6mm diameter
Retailer offers
FSA Gossamer SB20 Seatpost Black, 31.6mm, 350mm
Replacement option
Wellgo DH Flats
More parts (2)Fewer parts
SRAM X.5
SRAM X.4 trigger
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.35" Kenda Kinetics
- Drivetrain
- 8-speed
- Seatpost diameter
- 31.6 mm
- Bottom bracket / shell
- TruVativ
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Suntour Duro DJ, 130mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: Suntour Duro DJ, 130mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: SRAM X.4 trigger · Front derailleur: SRAM 3.0 · Rear derailleur: SRAM X.5 · Crankset: Truvativ Ruktion, 22/32+bash teeth · Bottom bracket: TruVativ · Cassette: Shimano HG-40 · Rear cogs: 8-speed, 11 - 32 teeth
Brakes
Inspect the brakes →Archived: Brakes: Avid BB-5 Mechanical w/7" rotor brakes, Avid FR-5 front/Avid FR- 5 rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Front: Alex SX-44, Rear: Ales SX-44, 32-hole · Hubs: Front: Formula, Rear: Shimano M475 · Front tire: 26 x 2.35" Kenda Kinetics
Controls and contact points
Archived: Handlebar: Brodie Lo Rise · Stem: Brodie 4-bolt · Seatpost: Brodie 2-bolt, 31.6mm diameter · Saddle: Brodie FR · Pedals: Wellgo DH Flats
