Lowest0.65:1
Highest4.00:1
Total range618%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.1; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Brodie Fury
Original specifications: Shimano Deore XT · 9-speed rear derailleur · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #21472- Model year
- 2010
- Category
- Mountain
- Original MSRP
- $1,199.00
- Sizes
- 14.5", 16.5", 18, 19.5", 21"
- Colors
- Black
- In this record
- 23 specifications · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- Black
- Frame
- 7005 butted aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build7005 butted aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 butted aluminum |
| Fork | Marzocchi Corsa RLO, 100mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | Shimano XT Shadow |
| Crankset | Shimano M443, 22/32/44 teeth |
| Cassette | Shimano HG50 |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Pedals | Wellgo WPD-823 |
Brakes
| Brakes | Shimano Hydraulic Disc brakes, Shimano hydraulic levers |
|---|
Cockpit & Contact Points
| Handlebar | Brodie Lo Rise Lite, 31.8 |
|---|---|
| Handlebar Extensions | Not included |
| Stem | Brodie XC 4-bolt |
| Saddle | WTB Pure V Sport |
| Seatpost | Brodie XC, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano RM65 Centerlock |
|---|---|
| Rims | Sun CR-18, 32-hole |
| Spokes | Stainless steel |
| Front Tire | 26 x 2.10" WTB Nanoraptor |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Brodie XC
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
Shimano HG50
More parts (7)Fewer parts
Wellgo WPD-823
WTB Pure V Sport
Shimano M443
22/32/44 teeth
Shimano Deore
Shimano XT Shadow
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Deore
Shimano RM65 Centerlock
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.10" WTB Nanoraptor
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Marzocchi Corsa RLO, 100mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi Corsa RLO, 100mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Deore · Front derailleur: Shimano Deore · Rear derailleur: Shimano XT Shadow · Crankset: Shimano M443, 22/32/44 teeth · Cassette: Shimano HG50 · Rear cogs: 9-speed, 11 - 34 teeth
Brakes
Inspect the brakes →Archived: Brakes: Shimano Hydraulic Disc brakes, Shimano hydraulic levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Sun CR-18, 32-hole · Hubs: Shimano RM65 Centerlock · Front tire: 26 x 2.10" WTB Nanoraptor
Controls and contact points
Archived: Handlebar: Brodie Lo Rise Lite, 31.8 · Stem: Brodie XC 4-bolt · Seatpost: Brodie XC, 27.2mm diameter · Saddle: WTB Pure V Sport · Pedals: Wellgo WPD-823
