Lowest0.65:1
Highest4.00:1
Total range618%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.3; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Brodie Cruzado
Original specifications: SRAM X0 · 9-speed rear derailleur · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #21470- Model year
- 2010
- Category
- Mountain
- Original MSRP
- $3,999.00
- Sizes
- 16", 17", 18", 19."
- Colors
- Brushed Titanium
- In this record
- 24 specifications · original MSRP
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- Brushed Titanium
- Frame
- 3Al/2.5V titanium
- Original equipment
- SRAM Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build3Al/2.5V titanium · SRAM Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 3Al/2.5V titanium |
| Fork | RockShox Reba SL, 100mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | SRAM Mix |
|---|---|
| Shifters | SRAM X.9 |
| Front Derailleur | SRAM X.9 |
| Rear Derailleur | SRAM X.0 |
| Crankset | Truvativ Stylo 3.3 GXP, 22/32/44 teeth |
| Bottom Bracket | TruVativ |
| Cassette | SRAM PG-990 |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Pedals | Not included |
Brakes
| Brakes | Avid Juicy 7 W/ 6" Rotor brakes, Avid Juicy 7 hydraulic levers |
|---|
Cockpit & Contact Points
| Handlebar | Syncros Gain |
|---|---|
| Handlebar Extensions | Not included |
| Stem | Syncros FLS Factory |
| Saddle | Ritchey Pro Streem V2 |
| Seatpost | Syncros Micro Adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Industry 9 AM |
|---|---|
| Rims | Stans ZTR Arch |
| Spokes | Industry 9 alloy, straight pull |
| Front Tire | 26 x 2.30" Syncros FLT |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Syncros Micro Adjust
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
26 x 2.30" Syncros FLT
More parts (6)Fewer parts
Ritchey Pro Streem V2
SRAM X.9
SRAM X.0
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
SRAM X.9
Syncros Gain
Syncros FLS Factory
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.30" Syncros FLT
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- TruVativ
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: RockShox Reba SL, 100mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: RockShox Reba SL, 100mm travel
Drivetrain
Check drivetrain wear →Archived: Group: SRAM Mix · Shifters: SRAM X.9 · Front derailleur: SRAM X.9 · Rear derailleur: SRAM X.0 · Crankset: Truvativ Stylo 3.3 GXP, 22/32/44 teeth · Bottom bracket: TruVativ · Cassette: SRAM PG-990 · Rear cogs: 9-speed, 11 - 34 teeth
Brakes
Inspect the brakes →Archived: Brakes: Avid Juicy 7 W/ 6" Rotor brakes, Avid Juicy 7 hydraulic levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Stans ZTR Arch · Hubs: Industry 9 AM · Front tire: 26 x 2.30" Syncros FLT
Controls and contact points
Archived: Handlebar: Syncros Gain · Stem: Syncros FLS Factory · Seatpost: Syncros Micro Adjust, 27.2mm diameter · Saddle: Ritchey Pro Streem V2 · Pedals: Not included
