Velopedia Bicycle Archive

2008 Brodie Zealot

Original specifications: Shimano XT drivetrain · 26" wheels · 34.1 lb published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #15558
Model year
2008
Category
Mountain
Original MSRP
$3,799.00
Sizes
XS, S, M, L
Colors
Dark Ano Red
Weight
34.1 lb
In this record
27 specifications · archived image · original MSRP
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2008 archived details

Published colors
Dark Ano Red
Frame
7005 aluminum
Original equipment
Shimano XT

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build7005 aluminum · Shimano XT · 26" wheels

Historical catalog variants

Archived sizes and colors

4 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

XSSML

Published colors

Dark Ano Red
View 4 archived size/color combinations
SizeColor
XSDark Ano Red
SDark Ano Red
MDark Ano Red
LDark Ano Red

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material7005 aluminum
ForkMarzocchi 55 TST2, 160mm travel
Fork MaterialSingle
Rear ShockRockShox Monarch 3.1, 160mm travel

Drivetrain

Component GroupShimano XT
ShiftersShimano XT
Front DerailleurShimano XT
Rear DerailleurShimano XT Shadow
CranksetShimano XT, 22/32/44 teeth
Bottom BracketShimano
CassetteShimano XT
Rear Cogs9-speed, 11 - 34 teeth
ChainShimano XT
PedalsCrank Brothers 5050x

Brakes

BrakesShimano XT Disc w/180mm Rotor brakes, Shimano XT hydraulic levers

Cockpit & Contact Points

Headset1 1/8" FSA Orbit X
HandlebarSyncros Bulk
Handlebar ExtensionsNot included
StemSyncros AMS
SaddleWTB Deva Team
SeatpostSyncros Derived, 31.6mm diameter

Wheels & Tires

HubsShimano XT Centerlock disc
RimsShimano XT Tubeless
SpokesShimano
Front Tire26 x 2.35" Intense Edge FRO Lite
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes44/32/22T · 11–34T · 9-speed
Lowest0.65:1 Highest4.00:1 Total range618%
Estimated speed At 90 RPM Lowest gear4.6 mph Highest gear28.6 mph

Uses front tire 26×2.35; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Seatpost · Original
Syncros Derived

31.6mm diameter

Retailer offers
Chain · Original
Shimano XT
Front tire · Original
26 x 2.35" Intense Edge FRO Lite Replacement search: 26x2.35 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (10)Fewer parts
Saddle · Original
WTB Deva Team
Crankset · Original
Shimano XT

22/32/44 teeth

Front derailleur · Original
Shimano XT
Rear derailleur · Original
Shimano XT Shadow
Shifters · Original
Shimano XT
Handlebar · Original
Syncros Bulk
Stem · Original
Syncros AMS
Headset · Original
1 1/8" FSA Orbit X
Rims · Original
Shimano XT Tubeless
Hubs · Original
Shimano XT Centerlock disc

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.35" Intense Edge FRO Lite
Drivetrain
9-speed
Seatpost diameter
31.6 mm
Bottom bracket / shell
Shimano
Equipment inspection checks 14 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 14 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Marzocchi 55 TST2, 160mm travel · Single

Archived: Fork: Marzocchi 55 TST2, 160mm travel · Rear shock: RockShox Monarch 3.1, 160mm travel

Archived: Group: Shimano XT · Shifters: Shimano XT · Front derailleur: Shimano XT · Rear derailleur: Shimano XT Shadow · Crankset: Shimano XT, 22/32/44 teeth · Bottom bracket: Shimano · Cassette: Shimano XT · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano XT

Archived: Brakes: Shimano XT Disc w/180mm Rotor brakes, Shimano XT hydraulic levers

Archived: Wheel size: 26" wheels · Rims: Shimano XT Tubeless · Hubs: Shimano XT Centerlock disc · Front tire: 26 x 2.35" Intense Edge FRO Lite

Controls and contact points

Archived: Headset: 1 1/8" FSA Orbit X · Handlebar: Syncros Bulk · Stem: Syncros AMS · Seatpost: Syncros Derived, 31.6mm diameter · Saddle: WTB Deva Team · Pedals: Crank Brothers 5050x
