Lowest1.36:1
Highest4.17:1
Total range306%
Velopedia Bicycle Archive
At a glance
Archive #1000014- Model year
- 2012
- Category
- Road
- Sizes
- 50cm, 53cm, 55cm, 57cm, 59cm, 61cm
- Colors
- Black/White, Celeste
- In this record
- 17 specifications · 2 archived images
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Black/White, Celeste
- Frame
- Infinito Carbon, Nanotech BAT
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildInfinito Carbon, Nanotech BAT
Frameset
| Frame Material | Infinito Carbon, Nanotech BAT |
|---|---|
| Fork | C2C K-VID Full carbon 1 1/8 |
Drivetrain
| Shifters | Shimano Ultegra STI 10spd |
|---|---|
| Front Derailleur | Shimano Ultegra |
| Rear Derailleur | Shimano Ultegra |
| Crankset | Shimano Ultegra 50/34t |
| Cassette | Shimano 105 10sp 12-25t |
| Chain | Shimano Ultegra |
| Pedals | nylon flat pedal |
Brakes
| Brakes | Shimano Ultegra |
|---|
Cockpit & Contact Points
| Headset | FSA Orbit CE Plus |
|---|---|
| Handlebar | FSA Wing Compact |
| Stem | FSA Carbon Pro carbon wrap |
| Saddle | Fizik Aliante Delta |
| Seatpost | FSA SL-K Carbon |
Wheels & Tires
| Rims | Fulcrum Racing 5 |
|---|---|
| Front Tire | Hutchinson Fusion 3 700x23 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano Ultegra
Retailer offers
Shimano Ultegra CN-6701 Chain 10 Speed, 116 Link
Specification match
Hutchinson Fusion 3 700x23
Retailer offers
Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23
700x23c
Replacement option
Hutchinson Fusion 3 on eBaySponsored links
Shimano 105 10sp 12-25t
More parts (10)Fewer parts
Fizik Aliante Delta
Shimano Ultegra 50/34t
Shimano Ultegra
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Ultegra
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Ultegra STI 10spd
FSA Wing Compact
FSA Carbon Pro carbon wrap
FSA SL-K Carbon
FSA Orbit CE Plus
Fulcrum Racing 5
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Hutchinson Fusion 3 700x23
- Drivetrain
- 10-speed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Infinito Carbon, Nanotech BAT · Fork: C2C K-VID Full carbon 1 1/8
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano Ultegra STI 10spd · Front derailleur: Shimano Ultegra · Rear derailleur: Shimano Ultegra · Crankset: Shimano Ultegra 50/34t · Cassette: Shimano 105 10sp 12-25t · Chain: Shimano Ultegra
Brakes
Inspect the brakes →Archived: Brakes: Shimano Ultegra
Wheels and tires
Check wheels and tires →Archived: Rims: Fulcrum Racing 5 · Front tire: Hutchinson Fusion 3 700x23
Controls and contact points
Archived: Headset: FSA Orbit CE Plus · Handlebar: FSA Wing Compact · Stem: FSA Carbon Pro carbon wrap · Seatpost: FSA SL-K Carbon · Saddle: Fizik Aliante Delta · Pedals: nylon flat pedal
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery2 images
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
