Lowest1.56:1
Highest4.42:1
Total range283%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
2006 Bianchi 928 Carbon/Centaur
Original specifications: Campagnolo Centaur drivetrain · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #11504- Model year
- 2006
- Category
- Road
- Sizes
- 50cm, 53cm, 55cm, 58cm, 61cm
- Colors
- Natural Carbon/White decals
- In this record
- 22 specifications · archived image
Original build928 Carbon · Campagnolo Centaur · 700c wheels
Frameset
| Frame Construction | Bonded |
|---|---|
| Frame Material | 928 Carbon |
| Fork | Bianchi Componenti |
| Fork Material | Carbon fiber, aero crown |
Drivetrain
| Component Group | Campagnolo Centaur |
|---|---|
| Shifters | Campagnolo Centaur Ergo |
| Front Derailleur | Campagnolo Centaur, 31.8mm |
| Rear Derailleur | Campagnolo Centaur |
| Crankset | FSA Carbon Pro, 39/53 teeth |
| Rear Cogs | 10-speed, 12 - 25 teeth |
| Pedals | Not included |
Brakes
| Brakes | Campagnolo Centaur brakes, Campagnolo Centaur Ergo levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated FSA Orbit ZS |
|---|---|
| Handlebar | ITM Wing |
| Handlebar Extensions | Not included |
| Stem | ITM Forged Lite |
| Saddle | Fi’zi:k Pavé |
| Seatpost | FSA Carbon Pro, 27.2mm diameter |
Wheels & Tires
| Hubs | Campagnolo Scirocco |
|---|---|
| Rims | Campagnolo Scirocco |
| Front Tire | 700 x 23C Continental Grand Prix |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 23C Continental Grand Prix
Retailer offers
Continental Grand Prix 5000 Clincher Tire Black, Black Chili, 700x23
700x23c
Model match
Other replacement options (1)
Continental Grand Prix 4 Season Clincher Tire Black-Duraskin, 700x23
700x23c
Model match
Continental Grand Prix on eBaySponsored links
FSA Carbon Pro
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
FSA Carbon Pro
39/53 teeth
More parts (6)Fewer parts
Campagnolo Centaur
31.8mm
Campagnolo Centaur
Campagnolo Centaur Ergo
1 1/8" integrated FSA Orbit ZS
Campagnolo Scirocco
Campagnolo Scirocco
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23C Continental Grand Prix
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Bonded · Fork: Bianchi Componenti · Carbon fiber, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Campagnolo Centaur · Shifters: Campagnolo Centaur Ergo · Front derailleur: Campagnolo Centaur, 31.8mm · Rear derailleur: Campagnolo Centaur · Crankset: FSA Carbon Pro, 39/53 teeth · Rear cogs: 10-speed, 12 - 25 teeth
Brakes
Inspect the brakes →Archived: Brakes: Campagnolo Centaur brakes, Campagnolo Centaur Ergo levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Campagnolo Scirocco · Hubs: Campagnolo Scirocco · Front tire: 700 x 23C Continental Grand Prix
Controls and contact points
Archived: Headset: 1 1/8" integrated FSA Orbit ZS · Handlebar: ITM Wing · Stem: ITM Forged Lite · Seatpost: FSA Carbon Pro, 27.2mm diameter · Saddle: Fi’zi:k Pavé · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
