2026 X-LAB RS5
Original manufacturer specifications including 105 drivetrain, 700C wheels, 9.54 kg / 21.03 lbs (Size L) published weight.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Road
- Original MSRP
- $1,399.00
- Sizes
- XS, S, M, L, XL
- Colors
- WaveBreaker White, Hydrostatic Blue
- Weight
- 9.54 kg / 21.03 lbs (Size L)
- Geometry
- 5 manufacturer sizes · Geometry context
- Record coverage
- 22 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001316
Frameset
| Frame Construction | XDS X6 Alloy Frame, UDH Compatible |
|---|---|
| Frame Material | Aluminum |
| Fork | XDS Carbon Fork, 100x12mm Thru-axle |
| Fork Material | Carbon |
Drivetrain
| Component Group | 105 |
|---|---|
| Shifters | Shimano 105 ST-R7120 |
| Front Derailleur | Shimano 105 FD-R7100 |
| Rear Derailleur | Shimano 105 RD-R7100 |
| Crankset | Branta Alloy Power Meter Crankset, 52-36T; 24mm Steel Spindle, Apple Find My Anti-Theft Technology |
| Bottom Bracket | BSA 24mm |
| Cassette | CS-R9012, 12-Speed, 11-34T |
| Chain | Sumc SX12 |
Brakes
| Brakes | Shimano 105 BR-R7170; Rotors: Shimano SM-RT56-S, F:160 R:160mm |
|---|
Cockpit & Contact Points
| Handlebar | Branta Alloy Integrated |
|---|---|
| Stem | Branta Alloy Integrated |
| Saddle | Branta R302, Steel Rails |
| Seatpost | XDS Carbon Seatpost, Aero Profile |
Wheels & Tires
| Wheels | Branta A35 SL, Alloy Rims |
|---|---|
| Front Tire | Branta R332, 700x32C, 60TPI; Max Tire Clearance: 38C |
| Rear Tire | Branta R332, 700x32C, 60TPI; Max Tire Clearance: 38C |
| Wheel Size | 700C |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Seat tube | 440 mm | 480 mm | 510 mm | 540 mm | 560 mm |
| Top tube | 515 mm | 530 mm | 548 mm | 568 mm | 585 mm |
| Head tube | 115 mm | 135 mm | 155 mm | 180 mm | 205 mm |
| Head-tube angle | 71° | 72° | 73° | 73° | 73° |
| Seat-tube angle | 75° | 74° | 74° | 73° | 73° |
| Chainstay / rear center | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 999 mm | 1001 mm | 1004 mm | 1018 mm | 1033 mm |
| Bottom-bracket drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Reach | 371 mm | 375 mm | 381 mm | 387 mm | 394 mm |
| Stack | 530 mm | 553 mm | 575 mm | 599 mm | 623 mm |
| Standover height | 725 mm | 758 mm | 784 mm | 810 mm | 831 mm |
| Front center | 590 mm | 592 mm | 596 mm | 609 mm | 624 mm |
| Fork length / axle-to-crown | 386 mm | 386 mm | 386 mm | 386 mm | 386 mm |
Geometry source: X-LAB first-party Basic geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XS geometry
Archive context: Its wheelbase of 999 mm sits toward the longer end. Its bottom-bracket drop of 75 mm sits toward the deeper-drop end. The chainstay of 420 mm sits somewhat longer than typical.
Compared with 64 distinct road geometries in the XS-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: Its stack of 553 mm sits toward the taller end. The chainstay of 420 mm sits somewhat longer than typical. Its wheelbase of 1001 mm sits somewhat longer than typical.
Compared with 88 distinct road geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: The head angle of 73° sits toward the steeper end. Its stack of 575 mm sits somewhat taller than typical. Its bottom-bracket drop of 75 mm sits somewhat deeper than typical.
Compared with 88 distinct road geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: The seat angle of 73° sits toward the more relaxed end. Its bottom-bracket drop of 75 mm sits toward the deeper-drop end. Its stack of 599 mm sits toward the taller end.
Compared with 77 distinct road geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: Its bottom-bracket drop of 75 mm sits toward the deeper-drop end. Its reach of 394 mm sits toward the shorter end. Its stack of 623 mm sits toward the taller end.
Compared with 63 distinct road geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
Shimano 105 BR-R7170
Brake model identified — verify pad shape
Shimano 105 FD-R7100
Interpreted as Shimano 105 · 12-speed · mechanical Exact archived model
Shimano 105 RD-R7100
Interpreted as Shimano 105 · 12-speed · mechanical Exact archived model
More qualified parts (1)
Shimano 105 ST-R7120
Interpreted as Shimano 105 · 12-speed · mechanical Exact archived model
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 12-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
- Bottom bracketTurn the cranks slowly, feel for rough bearings and check for side-to-side play. Creaking under load deserves investigation but does not identify the source by itself.Inspect the bottom bracket and shell →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 X-LAB RS5 · Road · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: XDS X6 Alloy Frame, UDH Compatible · Fork: XDS Carbon Fork, 100x12mm Thru-axle · Carbon
Drivetrain
Check drivetrain wear →Archived: Group: 105 · Shifters: Shimano 105 ST-R7120 · Front derailleur: Shimano 105 FD-R7100 · Rear derailleur: Shimano 105 RD-R7100 · Crankset: Branta Alloy Power Meter Crankset, 52-36T; 24mm Steel Spindle, Apple Find My Anti-Theft Technology · Bottom bracket: BSA 24mm · Cassette: CS-R9012, 12-Speed, 11-34T · Chain: SUMC SX12
Brakes
Inspect the brakes →Archived: Brakes: Shimano 105 BR-R7170; Rotors: Shimano SM-RT56-S, F:160 R:160mm
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700C · Wheels: Branta A35 SL, Alloy Rims · Front tire: Branta R332, 700x32C, 60TPI; Max Tire Clearance: 38C · Rear tire: Branta R332, 700x32C, 60TPI; Max Tire Clearance: 38C
Controls and contact points
Archived: Handlebar: Branta Alloy Integrated · Stem: Branta Alloy Integrated · Seatpost: XDS Carbon Seatpost, Aero Profile · Saddle: Branta R302, Steel Rails
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
