2001 Waterford RSE

Archived: 2001 Waterford RSE · Touring · Published sizes: 48cm, 49cm, 50cm, 51cm, 52cm, 53cm, 54cm, 55cm, 56cm, 57cm, 58cm, 59cm, 60cm, 61cm, 62cm, 63cm, 64cm, 65cm, 66cm, 67cm, 68cm, Custom

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: Silver-brazed, lugged · Fork: Waterford · Reynolds 531, semi-sloping crown

• Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.
• Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Archived: Group: Shimano Ultegra Triple · Shifters: Shimano Ultegra STI Dual Control · Front derailleur: Shimano Ultegra, bottom-pull/clamp-on 28.6mm · Rear derailleur: Shimano Ultegra GS · Crankset: Shimano Ultegra, 30/42/53 teeth · Bottom bracket: Shimano BB-5500, 118.5mm spindle · Rear cogs: 9-speed, 12 - 27 teeth · Chain: Shimano CN-HG92, 1/2 x 3/32"

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Shimano Deore XT V-Brake brakes, Shimano Ultegra STI Dual Control levers

• Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 700c wheels · Rims: Mavic Open Pro, 32-hole · Hubs: Shimano Ultegra · Front tire: 700 x 32c Michelin CX Sprint

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.

Archived: Headset: 1" Cane Creek C2 · Handlebar: ITM Super Italian Pro 260 · Stem: ITM Eclipse · Seatpost: American Classic, 27.2mm diameter · Saddle: Fi'zi:k Pave, titanium rails · Pedals: Not included

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
