2026 Trek Check-OUT SL Frameset

Frame specifications: ML - 2.40 kg / 5.3 lbs published weight · geometry for 5 published sizes.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900000789
Model year
2026
Category
Gravel & Cyclocross
Original MSRP
$3,699.99
Sizes
S, M, ML, L, XL
Colors
Era White/Blue Sage
Weight
ML - 2.40 kg / 5.3 lbs
Geometry
5 manufacturer sizes
In this record
5 specifications · archived image · original MSRP · geometry
Campaign
Frame specificationsCarbon fiber · 700c

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMMLLXL

Published colors

Era White/Blue Sage

Frameset

Frame Construction500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12mm chamfered thru axle, 55mm travel
Frame MaterialCarbon fiber
Rear ShockRockShox SIDluxe Ultimate 3P, 170mmx27.5mm

Cockpit & Contact Points

Headset1-1/8'' threadless, sealed cartridge bearings

Wheels & Tires

Wheel Size700c

Geometry

5 sizes · 14 measurements

Frame measurements by size.

All geometry measurements5 sizes · 14 measurements
MeasurementSMMLLXL
Seat tube440 mm470 mm520 mm540 mm560 mm
Effective top tube564 mm589 mm597 mm613 mm628 mm
Head tube94 mm133 mm149 mm170 mm193 mm
Head-tube angle68.8°69°69.4°69.5°69.4°
Seat-tube angle74.6°74.2°73.7°73°72.6°
Chainstay / rear center442 mm442 mm442 mm442 mm442 mm
Wheelbase1081 mm1105 mm1117 mm1135 mm1150 mm
Bottom-bracket drop70 mm70 mm70 mm68 mm68 mm
Reach395 mm407 mm417 mm427 mm435 mm
Stack580 mm617 mm634 mm652 mm673 mm
Standover height772 mm804 mm838 mm846 mm852 mm
Fork offset / rake45 mm45 mm45 mm45 mm45 mm
Trail92 mm91 mm88 mm88 mm88 mm
Wheel size700c700c700c700c700c

Dimensions as recorded.

Frame standardsQuick reference before buying parts

Recorded interfaces. Confirm the frame and included hardware before ordering parts.

Headset
1-1/8'' threadless, sealed cartridge bearings
