Velopedia Bicycle Archive
Surly Ice Cream Truck - Warm Cheese
Original specifications: 26" wheels · 34 lb 11 oz, size Medium published weight · geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
At a glance
- Model year
- Not published by manufacturer
- Category
- Mountain
- Original MSRP
- $2,349.00
- Sizes
- S, M, L, XL
- Colors
- Warm Cheese
- Weight
- 34 lb 11 oz, size Medium
- Geometry
- 4 manufacturer sizes
- In this record
- 21 specifications · 6 archived images · original MSRP · geometry
- Archive ID
- 900000874
Original buildSteel · 26"
Frameset
| Frame Construction | Surly Ice Cream Truck 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated |
|---|---|
| Frame Material | Steel |
| Fork | Surly Ice Cream Truck 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated |
| Fork Material | Steel |
Drivetrain
| Shifters | Shimano SLX M7100 |
|---|---|
| Rear Derailleur | Shimano SLX M7100 |
| Crankset | Race Face Aeffect, 30T |
| Bottom Bracket | Race Face |
| Cassette | Shimano SLX 10-51t, 12-speed |
| Chain | KMC X12 |
Brakes
| Brakes | Brake Calipers: Tektro Gemini HD-M520; Brake Levers: Tektro Gemini HD-M520; Rotors: Tektro 180/160, 6-Bolt |
|---|
Cockpit & Contact Points
| Headset | Cane Creek 40 |
|---|---|
| Handlebar | Salsa Rustler |
| Stem | Promax DA-296, 31.8mm |
| Saddle | WTB Volt |
| Seatpost | Promax SP-2019, 0 offset (400mm length) |
Wheels & Tires
| Hubs | (F) Novatec 15x150mm / (R) Novatec 12x197mm |
|---|---|
| Rims | Surly My Other Brother Daryl Rims, 32h |
| Front Tire | Surly Lou, 26 x 4.8", 120tpi, tubeless ready |
| Rear Tire | Surly Bud, 26 x 4.8", 120tpi, tubeless ready |
| Wheel Size | 26" |
Geometry
Frame measurements by size.
Published frame view
Select an available measurement to locate it on the frame.
All geometry measurements4 sizes · 16 measurements
| Measurement | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| Seat tube | 366 mm | 419 mm | 470 mm | 521 mm |
| Effective top tube | 585 mm | 610 mm | 635 mm | 660 mm |
| Head tube | 95 mm | 105 mm | 115 mm | 125 mm |
| Head-tube angle | 68° | 68° | 68° | 68° |
| Seat-tube angle | 73° | 73° | 73° | 73° |
| Chainstay / rear center | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1105 mm | 1131 mm | 1157 mm | 1182 mm |
| Bottom-bracket drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Reach | 405 mm | 427 mm | 449 mm | 472 mm |
| Stack | 588 mm | 598 mm | 607 mm | 616 mm |
| Standover height | 777 mm | 803 mm | 831 mm | 860 mm |
| Fork offset / rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Fork length / axle-to-crown | 483 mm | 483 mm | 483 mm | 483 mm |
| Crank length | 170 mm | 175 mm | 175 mm | 175 mm |
| Stem length | 60 mm | 70 mm | 80 mm | 90 mm |
| Handlebar width | 750 mm | 800 mm | 800 mm | 800 mm |
Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.
Gearing
Lower ratios provide more mechanical advantage for climbing. Higher ratios turn the rear wheel farther with each crank revolution.
Parts & serviceability
Find replacement parts
More parts (5)
Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases.
Bike-specific inspection checklist 20 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: Surly Ice Cream Truck - Warm Cheese · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Surly Ice Cream Truck 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated · Fork: Surly Ice Cream Truck 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated · Steel
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano SLX M7100 · Rear derailleur: Shimano SLX M7100 · Crankset: Race Face Aeffect, 30T · Bottom bracket: Race Face · Cassette: Shimano SLX 10-51t, 12-speed · Chain: KMC X12
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: Tektro Gemini HD-M520; Brake Levers: Tektro Gemini HD-M520; Rotors: Tektro 180/160, 6-Bolt
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" · Rims: Surly My Other Brother Daryl Rims, 32h · Hubs: (F) Novatec 15x150mm / (R) Novatec 12x197mm · Front tire: Surly Lou, 26 x 4.8", 120tpi, tubeless ready · Rear tire: Surly Bud, 26 x 4.8", 120tpi, tubeless ready
Controls and contact points
Archived: Headset: Cane Creek 40 · Handlebar: Salsa Rustler · Stem: Promax DA-296, 31.8mm · Seatpost: Promax SP-2019, 0 offset (400mm length) · Saddle: WTB Volt
Before and during the test ride
Follow the full used-bike inspection order →Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery6 images
Checking current listings…
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
