1997 Supercross Speed
BMX bicycle from the Velopedia specification archive.
- Original MSRP
- $499.95
- Sizes
- Pro, XL
- Colors
- Red, white
- Weight
- 22
- Archive ID
- 66516
Image not yet recovered
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6/6013 T6 aluminum |
| Fork | Supercross Pro |
| Fork Material | 4130 chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | Supercross Powercrank 1-piece chromoly, 44 teeth |
| Bottom Bracket | One piece |
| BB Shell Width | American |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC 410, 1/2 x 3/32" |
| Pedals | Tech Pro Platform |
Brakes
| Brakes | Tektro 876AG V-Brake brakes, Dia-Compe MX-99 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Compe Kontak Aheadset ST-2 |
|---|---|
| Handlebar | Supercross Pro Bar |
| Handlebar Extensions | N/A |
| Stem | Supercross |
| Saddle | Supercross BMX |
| Seatpost | Supercross aluminum micro-adjust, 27.2 mm diameter |
Wheels & Tires
| Hubs | Tech Sealed BMX |
|---|---|
| Rims | Velocity, 36-hole |
| Spokes | Steel, 2.0mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | Front: 20 x 2.125" Tioga Comp III, Rear: 20 x 1.75" Tioga Comp III |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
