1998 Sunn Total
Mountain bike, front & rear suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $889.00
- Sizes
- Large, medium, small, xlarge
- Colors
- Chrome-plated
- Archive ID
- 71790
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Tange chromoly, double-butted |
| Fork | Sunn Elastobsys |
| Fork Material | 7075 aluminum, triple-clamp crown |
| Rear Shock | Sunn Flex, 1.0" travel |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Grip Shift ESP 7.0 |
| Front Derailleur | Shimano Alivio, bottom-pull |
| Rear Derailleur | Grip Shift ESP 5.0 |
| Crankset | Rudd, 24/34/42 teeth |
| Bottom Bracket | Shimano BB-LP27 |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | Sachs PC-41, 1/2 x 3/32" |
| Pedals | Resin |
Brakes
| Brakes | Avid 1D-10 brakes, Avid AD-1.0 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Tech DT2 |
|---|---|
| Handlebar | Rudd alloy |
| Handlebar Extensions | Not included |
| Stem | Rudd |
| Saddle | Selle Italia Nitrox |
| Seatpost | Rudd alloy |
Wheels & Tires
| Hubs | Sachs Centera |
|---|---|
| Rims | Rigida Aries, 32-hole |
| Spokes | Stainless steel, 2.0mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" Ritchey Z-Max |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
