2027 Specialized Turbo Creo 2 Comp - Shimano GRX Di2
Original manufacturer specifications including 14.65 kg (32 lb, 4.8 oz) published weight, geometry for 6 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2027
- Category
- Gravel & Cyclocross
- Original MSRP
- $6,999.99
- Sizes
- 49, 52, 54, 56, 58, 61
- Colors
- Gloss Laurel Green Metallic, Gloss Desert Metallic
- Weight
- 14.65 kg (32 lb, 4.8 oz)
- Geometry
- 6 manufacturer sizes · Geometry context
- Record coverage
- 21 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001139
Frameset
| Frame Construction | FACT 11r carbon, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, 12x142mm |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Future Shock 3.2 w/ Smooth Boot, 12x100mm thru-axle, flat-mount disc |
Drivetrain
| Shifters | Shimano GRX Di2 RX715/717 |
|---|---|
| Rear Derailleur | Shimano GRX Di2 RD-RX717 12-speed |
| Crankset | SRAM Alloy Crankset, DUB interface |
| Cassette | Shimano Deore M6100, 12-speed w/ Hyperglide+, 10-51t |
| Chain | Shimano Deore M6100, 12-speed w/quick link |
Brakes
| Brakes | (F) Shimano GRX RX410, hyrdaulic disc / (R) Shimano GRX RX410, hyrdaulic disc |
|---|
Cockpit & Contact Points
| Handlebar | Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare |
|---|---|
| Stem | Future Stem, Comp |
| Saddle | Body Geometry Power Sport, steel rails |
| Seatpost | X-Fusion Manic Dropper, 50mm travel |
Wheels & Tires
| Wheels | (F) DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples / (R) DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples |
|---|---|
| Front Tire | Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready |
| Rear Tire | Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready |
E-bike System
| Motor | Specialized 1.2 SL Custom Lightweight Motor |
|---|---|
| Battery | Specialized SL1-320, fully integrated, 320Wh |
| Display/Remote | Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote |
| Charger | Custom charger, 48V System w/ SL system charger plug |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Seat tube | 410 mm | 430 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Effective top tube | 531 mm | 540 mm | 554 mm | 572 mm | 590 mm | 613 mm |
| Head tube | 90 mm | 90 mm | 108 mm | 120 mm | 153 mm | 180 mm |
| Head-tube angle | 71° | 71° | 71° | 71° | 71° | 71° |
| Seat-tube angle | 74° | 74° | 74° | 73.5° | 73.5° | 73° |
| Chainstay / rear center | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1022 mm | 1031 mm | 1046 mm | 1059 mm | 1079 mm | 1097 mm |
| Bottom-bracket drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Bottom-bracket height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Reach | 365 mm | 374 mm | 383 mm | 392 mm | 401 mm | 410 mm |
| Stack | 578 mm | 578 mm | 595 mm | 607 mm | 638 mm | 663 mm |
| Fork offset / rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Front center | 600.1 mm | 609 mm | 623.8 mm | 636.6 mm | 656.2 mm | 673.8 mm |
| Trail | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Fork length / axle-to-crown | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Crank length | 165 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm | 175 mm |
| Stem length | 60 mm | 70 mm | 80 mm | 90 mm | 100 mm | 100 mm |
| Handlebar width | 380 mm | 400 mm | 420 mm | 420 mm | 440 mm | 440 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
49 geometry
Archive context: Its reach of 365 mm sits toward the shorter end. Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. The head angle of 71° sits toward the steeper end.
Compared with 88 distinct electric-assist geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 49 geometry 52 geometry
Archive context: Its reach of 374 mm sits toward the shorter end. Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. Its wheelbase of 1031 mm sits toward the shorter end.
Compared with 102 distinct electric-assist geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 52 geometry 54 geometry
Archive context: Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. The chainstay of 435 mm sits toward the shorter rear-center end. Its wheelbase of 1046 mm sits toward the shorter end.
Compared with 102 distinct electric-assist geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 54 geometry 56 geometry
Archive context: Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. Its stack of 607 mm sits toward the lower end. Its reach of 392 mm sits toward the shorter end.
Compared with 91 distinct electric-assist geometries in the Large-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 56 geometry 58 geometry
Archive context: Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. Its reach of 401 mm sits toward the shorter end. The chainstay of 435 mm sits toward the shorter rear-center end.
Compared with 74 distinct electric-assist geometries in the XL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 58 geometry 61 geometry
Archive context: Its bottom-bracket drop of 80 mm sits toward the deeper-drop end. The seat angle of 73° sits somewhat more relaxed than typical. Its reach of 410 mm sits somewhat shorter than typical.
Compared with 16 distinct electric-assist geometries in the XXL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 61 geometry Parts & serviceability
Find replacement parts
Shimano Deore M6100, 12-speed w/quick link
Interpreted as Shimano Deore · 12-speed Exact archived model
SRAM Alloy Crankset, DUB interface
Named archived component — verify exact version
Shimano GRX Di2 RD-RX717 12-speed
Interpreted as Shimano GRX · 12-speed · Di2 Exact archived model
More qualified parts (2)
Shimano GRX Di2 RX715/717
Interpreted as Shimano GRX · 12-speed · Di2 Component family — verify exact version
Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
Named archived component — verify dimensions
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesBoth brakes should stop firmly and release without rubbing. Inspect pad thickness, rotor wear and alignment, and check the cables or hoses for damage.Inspect the brakes →
- E-bike systemConfirm the main battery charges with the correct charger, locks securely into its mount and has no case damage, swelling, corrosion or overheating marks. Power the bike on from cold, test every assist mode and ask for available battery-health and diagnostic records.Check the battery and electronics →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 24 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Specialized Turbo Creo 2 Comp - Shimano GRX Di2 · Electric-assist · Published sizes: 49, 52, 54, 56, 58, 61
Frame and fork
Inspect the frame and fork →Archived: Frame: FACT 11r carbon, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, 12x142mm · Fork: Future Shock 3.2 w/ Smooth Boot, 12x100mm thru-axle, flat-mount disc
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano GRX Di2 RX715/717 · Rear derailleur: Shimano GRX Di2 RD-RX717 12-speed · Crankset: SRAM Alloy Crankset, DUB interface · Cassette: Shimano Deore M6100, 12-speed w/ Hyperglide+, 10-51t · Chain: Shimano Deore M6100, 12-speed w/quick link
Brakes
Inspect the brakes →Archived: Brakes: (F) Shimano GRX RX410, hyrdaulic disc / (R) Shimano GRX RX410, hyrdaulic disc
Wheels and tires
Check wheels and tires →Archived: Front tire: Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready · Rear tire: Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready
Controls and contact points
Archived: Handlebar: Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare · Stem: Future Stem, Comp · Seatpost: X-Fusion Manic Dropper, 50mm travel · Saddle: Body Geometry Power Sport, steel rails
E-bike system
Check the battery and electronics →Archived: Motor: Specialized 1.2 SL Custom Lightweight Motor · Battery: Specialized SL1-320, fully integrated, 320Wh · Display: Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote · Charger: Custom charger, 48V System w/ SL system charger plug
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
