2010 Scott Spark JR 20
Juvenile mountain bike, suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $499.99
- Sizes
- 20"
- Colors
- White/Red
- Archive ID
- 20457
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 Hydroformed Aluminum |
| Fork | RST Cappa 20, 50mm travel |
| Fork Material | Single |
| Rear Shock | Apro SD, 65mm |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano SL-RS35-6 Revo Shifter |
| Front Derailleur | Shimano FD-M190, clamp on |
| Rear Derailleur | Shimano TY18 GS |
| Crankset | Lasco Double 140mm, 34/42 teeth |
| Bottom Bracket | TH M-1 |
| Cassette | Shimano MF-TZ 20 |
| Rear Cogs | 6-speed, 14 - 28 teeth |
| Pedals | VP-570 |
Brakes
| Brakes | Lee-Chi 209 P brakes, Tektro JL510-TS levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless VP-A71 |
|---|---|
| Handlebar | Scott Junior Flat Bat 540mm |
| Handlebar Extensions | Not included |
| Stem | HL-TDS-C41-8 15° |
| Saddle | Junior Racing VL-50610 |
| Seatpost | Scott SP-252, 26.8mm diameter |
Wheels & Tires
| Hubs | Front: JY-433 Nutted, Rear: JY-434 Nutted |
|---|---|
| Rims | Alex C-1000, 32-hole |
| Spokes | Stainless steel, 15ga. (1.8mm) straight gauge |
| Front Tire | 20 x 2.0" K-829 / XC- Type |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
