Velopedia Bicycle Archive
2001 Schwinn Automatic Trail
Freestyle/jumping bicycle from the Velopedia specification archive.
- Original MSRP
- $379.95
- Sizes
- Pro
- Colors
- Matte Grey, Matte Army Green
- Archive ID
- 35199
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Chromoly |
| Fork | Schwinn |
| Fork Material | Chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | Schwinn XS OS tubular cromoly 3-piece, 38 teeth |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | 1/2 x 1/8" |
| Pedals | Schwinn XS Comp aluminum platform |
Brakes
| Brakes | Tektro U-brake rear brakes, Tektro aluminum rear levers |
|---|
Cockpit & Contact Points
| Headset | Dia-Compe SB-1-F |
|---|---|
| Handlebar | Chromoly 2-Piece |
| Handlebar Extensions | Not included |
| Stem | Schwinn alloy A-Head |
| Saddle | Schwinn 2-Piece |
| Seatpost | Steel micro-adjust, 26.6mm diameter |
Wheels & Tires
| Hubs | Aluminum |
|---|---|
| Rims | Aluminum, double wall, 48-hole |
| Front Tire | Front: 20 x 2.125" Schwinn XS Dirt Diggler, Rear: 20 x 1.85" Schwinn XS Dirt Diggler |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
