Velopedia Bicycle Archive
1996 Rocky Mountain Hammer
Mountain bike, non-suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $795.00
- Sizes
- 16", 17.5", 18.5", 19.5", 21"
- Colors
- Race red
- Weight
- 25.4
- Archive ID
- 51517
Image not yet recovered
Frameset
| Frame Construction | TIG-welded steel |
|---|---|
| Frame Material | Tange chromoly, triple-butted |
| Fork | Tange |
| Fork Material | Tange chromoly, butted, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Deore LX |
|---|---|
| Shifters | Grip Shift SRT-600 |
| Front Derailleur | Shimano Deore LX top-swing, top-pull/clamp-on 28.6 mm |
| Rear Derailleur | Shimano Deore LX SGS |
| Crankset | Sugino alloy, 22/32/44 teeth |
| Bottom Bracket | Shimano BB-UN52, 110 mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 28 teeth |
| Chain | Sachs SC40, 1/2 x 3/32" |
| Pedals | Fasten NWL-90K w/clips & straps |
Brakes
| Brakes | Shimano STX-RC M-System brakes, Tektro alloy levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Compe Kontak Aheadset ST-2 |
|---|---|
| Handlebar | RMB Stratos 2 |
| Handlebar Extensions | Not included |
| Stem | RMB custom 6061 alloy |
| Saddle | Vetta TT Tri-Shock, chromoly rails |
| Seatpost | RMB Stratos 2, 26.8 mm diameter |
Wheels & Tires
| Rims | Ritchey Rock 440, 32-hole |
|---|---|
| Spokes | Chung Nan stainless steel, 1.8mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.10" WTB VelociRaptor |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
