Ritchey Road Logic Frameset

Original specifications: 700C wheels · Frame weight: 1,750g (size 55); Fork weight: 380g (uncut steerer) published weight · geometry for 6 published sizes.

Share owner experience

At a glance

Model year: Not published by manufacturer
Category: Road
Original MSRP: $1,759.00
Sizes: 49cm, 51cm, 53cm, 55cm, 57cm, 59cm
Colors: Anthracite
Weight: Frame weight: 1,750g (size 55); Fork weight: 380g (uncut steerer)
Geometry: 6 manufacturer sizes
In this record: 7 specifications · 5 archived images · original MSRP · geometry
Archive ID: 900000537

Original buildSteel · 700C

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

49cm51cm53cm55cm57cm59cm

Published colors

Anthracite

Frameset

Frame Construction	heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
Frame Material	Steel
Fork	Ritchey WCS Carbon Road Fork included
Fork Material	Carbon Fiber

Drivetrain

Bottom Bracket	68mm - English threaded

Cockpit & Contact Points

Headset	WCS headset included (upper IS42/28.6 - 16mm stack height \| lower IS42/30)

Wheels & Tires

Wheel Size	700C

Geometry

6 sizes · 14 measurements

Frame measurements by size.

Measurement	49cm	51cm	53cm	55cm	57cm	59cm
Seat tube	465 mm	485 mm	505 mm	525 mm	545 mm	565 mm
Effective top tube	518 mm	532 mm	548 mm	563 mm	575 mm	590 mm
Top tube	511 mm	524 mm	537 mm	551 mm	563 mm	577 mm
Head tube	100 mm	115 mm	140 mm	160 mm	180 mm	200 mm
Head-tube angle	72°	72.5°	73°	73.5°	73.5°	73.5°
Seat-tube angle	75°	74.5°	74°	73.5°	73.5°	73.5°
Chainstay / rear center	410 mm	410 mm	415 mm	415 mm	415 mm	415 mm
Wheelbase	975 mm	981 mm	993 mm	996 mm	1008 mm	1018 mm
Bottom-bracket drop	72 mm	72 mm	72 mm	70 mm	70 mm	70 mm
Reach	382 mm	387 mm	391 mm	395 mm	401 mm	410 mm
Stack	507 mm	523 mm	549 mm	568 mm	587 mm	609 mm
Standover height	735 mm	753 mm	774 mm	795 mm	815 mm	835 mm
Fork offset / rake	46 mm	46 mm	46 mm	43 mm	43 mm	43 mm
Fork length / axle-to-crown	371 mm	371 mm	371 mm	371 mm	371 mm	371 mm

Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.
