2004 Redline Rogue
Freestyle/jumping bicycle from the Velopedia specification archive.
- Original MSRP
- $164.99
- Sizes
- Junior
- Colors
- Black/Chrome,White Flame, Red/Black
- Archive ID
- 89929
Current market
Checking current listings…Frameset
| Frame Construction | Pulse-welded |
|---|---|
| Frame Material | Hi-tensile steel |
| Fork | Redline |
| Fork Material | Hi-tensile steel, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | 1-piece chromoly 175mm, 44 teeth |
| Bottom Bracket | Loose ball |
| BB Shell Width | 68mm American |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410, 1/2 x 3/32" |
| Pedals | Redline aluminum |
Brakes
| Brakes | ProMax linear-pull brakes, Promax alloy levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless steel |
|---|---|
| Handlebar | Redline Pro hi-tensile |
| Handlebar Extensions | Not included |
| Stem | Aluminum 4 bolt |
| Saddle | Redline |
| Seatpost | Steel micro-adjust, 25.4mm diameter |
Wheels & Tires
| Hubs | Aluminum, nutted |
|---|---|
| Rims | Alex Y-303, 36-hole |
| Spokes | 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | Front: 20 x 2.00" Redline Logo, Rear: 20 x 1.75" Redline Logo |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
