2004 Redline Proline Junior
BMX bicycle from the Velopedia specification archive.
- Original MSRP
- $269.99
- Sizes
- Junior
- Colors
- Blue/White
- Archive ID
- 92021
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|
| Frame Material | 6061 T6 aluminum |
|---|
| Fork | Redline |
|---|
| Fork Material | 4130 chromoly, unicrown crown |
|---|
| Rear Shock | N/A |
|---|
Drivetrain
| Component Group | N/A |
|---|
| Shifters | N/A |
|---|
| Front Derailleur | N/A |
|---|
| Rear Derailleur | N/A |
|---|
| Crankset | 3-piece aluminum, 34 teeth |
|---|
| BB Shell Width | 68mm English |
|---|
| Rear Cogs | 1-speed, 14 teeth |
|---|
| Chain | KMC Z30, 1/2 x 1/8" |
|---|
| Pedals | Aluminum platform |
|---|
Brakes
| Brakes | ProMax mini-V brakes, ProMax linear-pull levers |
|---|
Cockpit & Contact Points
| Headset | 1" threadless aluminum |
|---|
| Handlebar | Aluminum, 4" rise |
|---|
| Handlebar Extensions | N/A |
|---|
| Stem | Proline Mini |
|---|
| Saddle | Redline Flight |
|---|
| Seatpost | Aluminum |
|---|
Wheels & Tires
| Hubs | Aluminum, Q/R |
|---|
| Rims | Alex VP-15, 28-hole/32-hole |
|---|
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
|---|
| Spoke Nipples | Brass nipples |
|---|
| Front Tire | 20 x 1 3/8" Tioga Comp III |
|---|
| Wheel Size | 20" wheels |
|---|
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
