Velopedia Bicycle Archive
2002 Redline RL-360
Freestyle/jumping bicycle from the Velopedia specification archive.
- Original MSRP
- $0.00
- Sizes
- Pro
- Colors
- Black w/ Flames, Chrome w/ Stripes, Royal Blue w/ Stripes
- Archive ID
- 37690
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Chromoly/hi-tensile steel |
| Fork | Redline |
| Fork Material | Chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | 1-piece forged 175mm, 44 teeth |
| Bottom Bracket | Loose ball |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z-410, 1/2 x 3/32" |
| Pedals | Redline aluminum |
Brakes
| Brakes | ProMax linear-pull rear brakes, Promax rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/4" Tioga |
|---|---|
| Handlebar | Redline Pro chromoly |
| Handlebar Extensions | Not included |
| Stem | Redline Proline |
| Saddle | Redline |
| Seatpost | Steel micro-adjust |
Wheels & Tires
| Hubs | Steel |
|---|---|
| Rims | Alex X-303, 36-hole |
| Spokes | 14ga. (2.0mm) straight gauge |
| Front Tire | Front: 20 x 2.00" Redline Logo, Rear: 20 x 1.75" Redline Logo |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
