2004 Raleigh C500
Hybrid bicycle from the Velopedia specification archive.
- Original MSRP
- $570.00
- Sizes
- 50cm, 53cm, 56cm, 59cm, 62cm
- Archive ID
- 31274
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum, double-butted |
| Fork | Raleigh |
| Fork Material | Aluminum, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | Shimano SL-R440 |
| Front Derailleur | Shimano FD-R443 |
| Rear Derailleur | Shimano Tiagra |
| Crankset | TruVativ Touro, 30/42/52 teeth |
| Bottom Bracket | TruVativ cartridge |
| Rear Cogs | 8-speed, 12 - 25 teeth |
| Chain | 1/2 x 3/32" |
| Pedals | Aluminum cage w/clips & straps |
Brakes
| Brakes | Tektro linear-pull brakes, Tektro Tenera levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless steel |
|---|---|
| Handlebar | Steel, 1" rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum, adjustable |
| Saddle | Selle Italia Onda |
| Seatpost | Aluminum, suspension |
Wheels & Tires
| Hubs | Front: aluminum QR, Rear: Shimano HB-RM40 |
|---|---|
| Rims | Alex AL-DM18, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 35c Vittoria Randonneur |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
