2025 Polygon Gili Velo

Original specifications: geometry for 1 published size.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900001905
Model year
2025
Category
City & Commuter
Original MSRP
$1,279.00
Sizes
ALL SIZE
Colors
Blue, Cream, Green, Red
Geometry
1 manufacturer size
In this record
23 specifications · 4 archived images · original MSRP · geometry
Campaign
Original buildAluminum

Manufacturer catalog

Published sizes and colors

1 size · 4 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

ALL SIZE

Published colors

BlueCreamGreenRed

Frameset

Frame ConstructionALX E-Commuting
Frame MaterialAluminum
ForkAlloy Rigid
Fork MaterialAluminum

Drivetrain

ShiftersShimano Altus SL-M315-R, 1X8-Speed Trigger
Rear DerailleurShimano Claris RD-R2000
CranksetProwheel NWA48A, 48T
CassetteShimano Tourney CS-HG200, 12-32T
ChainKMC X9
PedalsOne Piece PP Flat

Brakes

BrakesSHIMANO HYDRAULIC DISC; Levers: SHIMANO MT200; Rotors: SHIMANO SMRT26, 180MM, 6B

Cockpit & Contact Points

HeadsetSteel Threadless Semi Integrated, ZS 44/28.6 | ZS 56/40
HandlebarPOLYGON SPORT, W: 640mm, BB: 31.8mm, R/D: 0mm, B: 6degree
StemPolygon Sport, EXT: 45mm, BB: 31.8mm, R/D: 3mm
SaddleSelle Royal, Steel Ø7mm
SeatpostPolygon Sport, DXL: 30.9X400mm

Wheels & Tires

HubsF: Alloy 9X100mm 36H 6B
WheelsXL2 Tubeless Ready
RimsAlloy Double Wall H:21mm W: 17.9mm 406-17.5 36H AV Valve
Front TireVEE Speedster 20"X2.0" 406-50
Rear TireVEE Speedster 20"X2.0" 406-50

E-bike System

MotorBafang Rear Motor DC Motor 36V 250W
BatterySpard YT30240-X-CAN01 36V 7Ah Samsung Cell Smart BMS

Geometry

1 size · 13 measurements

Frame measurements by size.

All geometry measurements1 size · 13 measurements
MeasurementALL SIZE
Seat tube360 mm
Effective top tube570 mm
Head tube250 mm
Head-tube angle70°
Seat-tube angle74.5°
Actual seat-tube angle73.25°
Chainstay / rear center400 mm
Wheelbase1078.5 mm
Bottom-bracket drop35 mm
Bottom-bracket height290 mm
Reach412.5 mm
Stack567.9 mm
Standover height594 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes48T · 12–32T
Lowest1.50:1 Highest4.00:1 Total range267%
Estimated speed At 90 RPM Lowest gear8.0 mph Highest gear21.3 mph

Rear tire: 50-406 ETRTO.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Headset · Original
STEEL THREADLESS SEMI INTEGRATED

ZS 44/28.6 | ZS 56/40

Retailer offers
Cassette · Original
SHIMANO TOURNEY CS-HG200

12-32T

Front tire · Original
VEE SPEEDSTER 20"x2.0" 406-50
More parts (3)Fewer parts
Rear derailleur · Original
SHIMANO CLARIS RD-R2000
Shifters · Original
SHIMANO ALTUS SL-M315-R

1x8-SPEED TRIGGER

Seatpost · Original
POLYGON SPORT

DxL: 30.9X400mm

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Service essentialsQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
VEE SPEEDSTER 20"x2.0" 406-50Check: Verify the fitted tire’s size marking and rim type.
Rear tire
VEE SPEEDSTER 20"x2.0" 406-50Check: Verify the rear size; it may differ from the front.
Seatpost diameter
30.9 mmCheck: Read the post’s diameter marking; seat-clamp size differs.

Not confirmed in this record: Drivetrain · Bottom bracket / shell. Check the fitted parts for these details.

Bike-specific inspection checklist 24 checks based on 6 archived component groups Open checklistClose checklist
0 of 24 checked Progress stays in this browser for this record.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2025 Polygon Gili Velo · Electric-assist · Published sizes: ALL SIZE

Archived: Frame: ALX E-COMMUTING · Fork: ALLOY RIGID · Aluminum

Archived: Shifters: SHIMANO ALTUS SL-M315-R, 1x8-SPEED TRIGGER · Rear derailleur: SHIMANO CLARIS RD-R2000 · Crankset: PROWHEEL NWA48A, 48T · Cassette: SHIMANO TOURNEY CS-HG200, 12-32T · Chain: KMC X9

Archived: Brakes: SHIMANO HYDRAULIC DISC; Levers: SHIMANO MT200; Rotors: SHIMANO SMRT26, 180MM, 6B

Archived: Wheels: XL2 TUBELESS READY · Rims: ALLOY DOUBLE WALL H:21mm W: 17.9mm 406-17.5 36H AV VALVE · Hubs: F: ALLOY 9x100mm 36H 6B · Front tire: VEE SPEEDSTER 20"x2.0" 406-50 · Rear tire: VEE SPEEDSTER 20"x2.0" 406-50

Controls and contact points

Archived: Headset: STEEL THREADLESS SEMI INTEGRATED, ZS 44/28.6 | ZS 56/40 · Handlebar: POLYGON SPORT, W: 640mm, BB: 31.8mm, R/D: 0mm, B: 6degree · Stem: POLYGON SPORT, EXT: 45mm, BB: 31.8mm, R/D: 3mm · Seatpost: POLYGON SPORT, DxL: 30.9X400mm · Saddle: SELLE ROYAL, STEEL ø7mm · Pedals: ONE PIECE PP FLAT

Archived: Motor: BAFANG REAR MOTOR DC MOTOR 36V 250W · Battery: SPARD YT30240-X-CAN01 36V 7AH SAMSUNG CELL SMART BMS
