Velopedia Bicycle Archive
2005 Orbea Orca Record
Road race & triathlon bicycle from the Velopedia specification archive.
- Original MSRP
- $0.00
- Sizes
- 48cm, 50cm, 52cm, 54cm, 56cm, 58cm, 60cm
- Colors
- Red/Yellow, Orange/Yellow, White/Blue, Silver/Grey
- Archive ID
- 93200
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | Bonded/monocoque |
|---|---|
| Frame Material | Carbon fiber composite |
| Fork | Zeus FCM |
| Fork Material | Carbon fiber, aero crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Campagnolo Record |
|---|---|
| Shifters | Campagnolo Record Ergo |
| Front Derailleur | Campagnolo Record, braze-on |
| Rear Derailleur | Campagnolo Record |
| Crankset | FSA SL-K Mega Exo, 39/53 teeth |
| Bottom Bracket | FSA Mega EXO |
| BB Shell Width | 68mm English |
| Rear Cogs | 10-speed, 11 - 23 teeth |
| Chain | 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Campagnolo Record dual pivot brakes, Campagnolo Record Ergo levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated FSA Orbit 1 Carbon |
|---|---|
| Handlebar | ITM Wing Carbon |
| Handlebar Extensions | N/A |
| Stem | ITM Forged Lite Carbon Super Over |
| Saddle | Selle Italia SLR |
| Seatpost | Zeus Carbon |
Wheels & Tires
| Hubs | Mavic Ksyrium SSC |
|---|---|
| Rims | Mavic Ksyrium SSC SL, 18-hole/20-hole |
| Spokes | Mavic Zicral, aero |
| Spoke Nipples | Aluminum nipples |
| Front Tire | 700 x 23c Michelin Pro Race |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
