2018 Liv Langma Advanced SL 0
Original manufacturer specifications including geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2018
- Category
- Road
- Original MSRP
- $10,000.00
- Sizes
- XS, S, M, L
- Colors
- Smoke Carbon/Red/Blue/Magenta
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 23 preserved details · 4 archived images · original MSRP · preserved geometry
- Archive ID
- 900002338
Frameset
| Frame Construction | Advanced SL-grade composite, Integrated seatpost |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Advanced SL-grade composite, Full-composite OverDrive 2 steerer |
| Fork Material | Carbon Fiber |
| Rear Shock | N/A |
Drivetrain
| Shifters | SRAM RED E-Tap |
|---|---|
| Front Derailleur | SRAM RED E-Tap |
| Rear Derailleur | SRAM RED E-Tap |
| Crankset | SRAM RED, 34/50 w/Power Meter |
| Bottom Bracket | SRAM GXP |
| Cassette | SRAM RED 11x28, 11-Speed |
| Chain | SRAM Red |
| Pedals | N/A |
Brakes
| Brakes | SRAM RED |
|---|
Cockpit & Contact Points
| Handlebar | Giant Contact SLR, 31.8mm |
|---|---|
| Stem | Giant Contact SLR Flux |
| Saddle | Liv Contact SLR Forward |
| Seatpost | Advanced SL-grade composite, integrated design |
Wheels & Tires
| Hubs | Giant SLR 0 DBL WheelSystem; Pawl driver, QR, [F] 16h [R] 21h |
|---|---|
| Rims | Giant SLR 0 DBL WheelSystem; 30mm deep, 23mm wide, Tubeless, Full composite |
| Spokes | Giant SLR 0 DBL WheelSystem; Dynamic Balanced Lacing, bladed stainless |
| Front Tire | Giant Gavia AC 0 Tubeless, 700x25, Folding |
| Rear Tire | Giant Gavia AC 0 Tubeless, 700x25, Folding |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS | S | M | L |
|---|---|---|---|---|
| Seat tube | 630 mm | 670 mm | 710 mm | 750 mm |
| Top tube | 507 mm | 524 mm | 540 mm | 555 mm |
| Head tube | 115 mm | 130 mm | 150 mm | 170 mm |
| Head-tube angle | 71° | 72° | 72.5° | 72.5° |
| Seat-tube angle | 75° | 74.5° | 74° | 73.5° |
| Chainstay / rear center | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 972 mm | 974 mm | 981 mm | 991 mm |
| Bottom-bracket drop | 70 mm | 68 mm | 68 mm | 68 mm |
| Reach | 371 mm | 378 mm | 384 mm | 388 mm |
| Stack | 508 mm | 525 mm | 546 mm | 565 mm |
| Standover height | 679 mm | 701 mm | 728 mm | 754 mm |
| Fork offset / rake | 49 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 64 mm | 60 mm | 60 mm |
| Crank length | 165 mm | 170 mm | 170 mm | 172.5 mm |
| Stem length | 80 mm | 90 mm | 100 mm | 110 mm |
| Handlebar width | 380 mm | 380 mm | 400 mm | 420 mm |
| Wheel size | 700C | 700C | 700C | 700C |
Geometry source: Liv first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XS geometry
Archive context: The chainstay of 405 mm sits somewhat shorter than typical. Its wheelbase of 972 mm sits somewhat shorter than typical. Its stack of 508 mm sits somewhat lower than typical.
Compared with 16 distinct road geometries in the XS-equivalent size cohort from model years 2016–2020 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: Its wheelbase of 974 mm sits toward the shorter end. The chainstay of 405 mm sits somewhat shorter than typical. Its stack of 525 mm sits somewhat lower than typical.
Compared with 23 distinct road geometries in the Small-equivalent size cohort from model years 2016–2020 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: Its wheelbase of 981 mm sits toward the shorter end. The chainstay of 405 mm sits somewhat shorter than typical. Its stack of 546 mm sits somewhat lower than typical.
Compared with 23 distinct road geometries in the Medium-equivalent size cohort from model years 2016–2020 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: Its wheelbase of 991 mm sits toward the shorter end. Its stack of 565 mm sits toward the lower end. The chainstay of 405 mm sits somewhat shorter than typical.
Compared with 14 distinct road geometries in the Large-equivalent size cohort from model years 2016–2020 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry Parts & serviceability
Find replacement parts
SRAM Red
Interpreted as SRAM RED · 11-speed Named component · published drivetrain speed — verify exact version
SRAM RED 11x28, 11-Speed
Interpreted as SRAM RED · 11-speed Component family — verify exact version
SRAM GXP
Named archived component — verify dimensions
More qualified parts (4)
SRAM RED, 34/50 w/Power Meter
Named archived component — verify exact version
SRAM RED E-Tap
Interpreted as SRAM RED · 11-speed Named component · published drivetrain speed — verify exact version
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
SRAM RED E-Tap
Interpreted as SRAM RED · 11-speed Named component · published drivetrain speed — verify exact version
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
SRAM RED E-Tap
Interpreted as SRAM RED · 11-speed Named component · published drivetrain speed — verify exact version
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 11-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2018 Liv Langma Advanced SL 0 · Road · Published sizes: XS, S, M, L
Frame and fork
Inspect the frame and fork →Archived: Frame: Advanced SL-grade composite, Integrated seatpost · Fork: Advanced SL-grade composite, Full-composite OverDrive 2 steerer · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM RED E-Tap · Front derailleur: SRAM RED E-Tap · Rear derailleur: SRAM RED E-Tap · Crankset: SRAM RED, 34/50 w/Power Meter · Bottom bracket: SRAM GXP · Cassette: SRAM RED 11x28, 11-Speed · Chain: SRAM Red
Brakes
Inspect the brakes →Archived: Brakes: SRAM RED
Wheels and tires
Check wheels and tires →Archived: Rims: Giant SLR 0 DBL WheelSystem; 30mm deep, 23mm wide, Tubeless, Full composite · Hubs: Giant SLR 0 DBL WheelSystem; Pawl driver, QR, [F] 16h [R] 21h · Front tire: Giant Gavia AC 0 Tubeless, 700x25, Folding · Rear tire: Giant Gavia AC 0 Tubeless, 700x25, Folding
Controls and contact points
Archived: Handlebar: Giant Contact SLR, 31.8mm · Stem: Giant Contact SLR Flux · Seatpost: Advanced SL-grade composite, integrated design · Saddle: Liv Contact SLR Forward
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
