Velopedia Bicycle Archive
2003 Haro TR2.2 Cruiser
BMX cruiser bicycle from the Velopedia specification archive.
- Original MSRP
- $250.00
- Sizes
- Cruiser
- Colors
- Putty, SG Gray
- Archive ID
- 38587
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|
| Frame Material | Chromoly main triangle/hi-tensile steel rear stays |
|---|
| Fork | Haro BMX |
|---|
| Fork Material | Chromoly, unicrown crown |
|---|
| Rear Shock | N/A |
|---|
Drivetrain
| Component Group | N/A |
|---|
| Shifters | N/A |
|---|
| Front Derailleur | N/A |
|---|
| Rear Derailleur | N/A |
|---|
| Crankset | Haro Tubular Crmo, 40 teeth |
|---|
| Bottom Bracket | Fusion sealed |
|---|
| BB Shell Width | American |
|---|
| Rear Cogs | 1-speed, 17 teeth |
|---|
| Chain | KMC Z410 |
|---|
| Pedals | Fusion DX style platform, aluminum |
|---|
Brakes
| Brakes | Tektro alloy direct pull rear brakes, Tektro aluminum rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Tien Hsin Power Pro |
|---|
| Handlebar | Haro Sledgehammer 2k |
|---|
| Handlebar Extensions | N/A |
|---|
| Stem | Fusion |
|---|
| Saddle | Haro Padded |
|---|
| Seatpost | Fusion steel pillar |
|---|
Wheels & Tires
| Hubs | Haro Mid Flange |
|---|
| Rims | Alex X-303, 36-hole |
|---|
| Spokes | UCP, 14ga. (2.0mm) straight gauge |
|---|
| Spoke Nipples | Brass nipples |
|---|
| Front Tire | 24 x 1.85" Maxxis Max Daddy |
|---|
| Wheel Size | 24" wheels |
|---|
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
