2009 Gary Fisher AR Super Compact

Road race & triathlon bicycle from the Velopedia specification archive.

Original MSRP
$1,039.99
Sizes
49cm, 51cm, 53cm, 55cm, 57cm, 59cm, 61cm
Colors
Race Blue/Silver/White
Archive ID
17895
Image not yet recovered

Current market

Checking current listings…

Frameset

Frame ConstructionTIG-welded
Frame Material6066 aluminum
ForkBontrager Race Carbon
Fork MaterialCarbon fiber/aluminum steerer, aero crown
Rear ShockN/A

Drivetrain

Component GroupShimano Tiagra
ShiftersShimano Tiagra STI
Front DerailleurShimano Tiagra
Rear DerailleurShimano 105
CranksetFSA Gossamer, 34/50 teeth
CassetteSRAM PG-950
Rear Cogs9-speed, 12 - 26 teeth
PedalsVP-332A

Brakes

BrakesPromax RC-466A brakes, Shimano Tiagra STI levers

Cockpit & Contact Points

HeadsetIntegrated
HandlebarBontrager SSR VR Bend OS
Handlebar ExtensionsNot included
StemBontrager SSR OS
SaddleBontrager Race
SeatpostBontrager carbon

Wheels & Tires

HubsBontrager SSR
RimsBontrager SSR
Front Tire700 x 23c Bontrager Race Lite
Wheel Size700c wheels

More 2009 Gary Fisher Bicycles

View all

Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
