Velopedia Bicycle Archive
2002 Dahon Storm
Folding bicycle from the Velopedia specification archive.
- Original MSRP
- $0.00
- Sizes
- Large
- Colors
- Black
- Weight
- 28.6
- Archive ID
- 38246
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|
| Frame Material | Aluminum |
|---|
| Fork | Zone Trail, 3.0" travel |
|---|
| Fork Material | Aluminum, single triple-clamp crown |
|---|
Drivetrain
| Component Group | Folding mix |
|---|
| Shifters | SRAM ESP 4.0 |
|---|
| Front Derailleur | Shimano Alivio |
|---|
| Rear Derailleur | SRAM ESP 4.0 |
|---|
| Crankset | Sun Race |
|---|
| BB Shell Width | 68mm English |
|---|
| Rear Cogs | 8-speed |
|---|
| Chain | KMC Z-51, 1/2 x 3/16" |
|---|
| Pedals | VP aluminum |
|---|
Brakes
| Brakes | ProMax DSK-610J Mechanical Disc front/ProMax Elite rear brakes, Promax levers |
|---|
Cockpit & Contact Points
| Headset | 1" |
|---|
| Handlebar | Aluminum |
|---|
| Handlebar Extensions | Not included |
|---|
| Seatpost | Dahon |
|---|
Wheels & Tires
| Hubs | Aluminum, Q/R |
|---|
| Rims | Aluminum, aero |
|---|
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
|---|
| Spoke Nipples | Brass nipples |
|---|
| Front Tire | 26 x 1.95" |
|---|
| Wheel Size | 26" wheels |
|---|
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
