2018 Cannondale F-Si Team

Archived: 2018 Cannondale F-Si Team · Mountain · Published sizes: S (27.5"), M (29"), L (29"), XL (29")

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: F-Si, BallisTec Hi-MOD Carbon, SPEED SAVE, PF30A, 1.5 Si Head Tube, Ai Offset, 27.5” (S), 29” (M-XL) · Fork: Lefty 2.0 Carbon, 2Spring, 100mm, XLR Isolated Damper Technology with XC+ tune and XLoc remote, 55mm offset (29), 50mm offset (27.5) · Carbon

• Inspect the frame in bright light, especially the head tube, bottom-bracket area, chainstays and clamped surfaces. Look for cracks, ripples, crushed sections or signs of impact.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.

Archived: Fork: Lefty 2.0 Carbon, 2Spring, 100mm, XLR Isolated Damper Technology with XC+ tune and XLoc remote, 55mm offset (29), 50mm offset (27.5)

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Shifters: SRAM XX1 Eagle, 12-speed · Rear derailleur: SRAM XX1 Eagle, 12-speed · Crankset: SRAM XX1 Eagle, BB30, 34T, Ai Custom · Bottom bracket: Cannondale Alloy PressFit30 · Rear cogs: SRAM XG1295 Eagle, 10-50, 12-speed · Chain: SRAM PCX01 Eagle , 12-speed

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: SRAM Level Ultimate, Centerline Rotors 180/160mm

• Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 27.5" · Rims: ENVE Carbon M50, Tubeless Ready · Hubs: Lefty 60 front, C36 DT-Swiss Rear, Star Ratchet, 135x9mm, 28 hole (Ai Offset dish - Rear), DT QR · Front tire: Schwalbe Rocket Ron EVO Snakeskin, 29/27.5x2.25”, folding, Tubeless Ready · Rear tire: Schwalbe Rocket Ron EVO Snakeskin, 29/27.5x2.25”, folding, Tubeless Ready

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play. Inspect the carbon rims closely for impact marks, cracks, delamination or damage around spoke holes and bead hooks.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance. This record indicates different front and rear wheel diameters, so verify each tire at its correct end.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.
• Confirm whether the bike is actually set up tubeless, whether both tires hold pressure, and when sealant and rim tape were last serviced.

Archived: Headset: Cannondale HeadShok Si · Handlebar: FSA K-Force Carbon, flat, 760mm · Stem: Cannondale C1, 6061 Alloy, 1.5”, 31.8, -5 deg. · Seatpost: Cannondale SAVE2 Carbon, 27.2x400mm · Saddle: Prologo Zero II TiRox Rail

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure. Look particularly closely for crushing, scoring or cracks at carbon handlebar clamp areas.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
