2027 Spot Diggity 125 Frame Only
Original manufacturer specifications including 29 wheels, S: 5.1 | M: 5.2 | L: 5.3 | XL: 5.4 published weight, geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2027
- Category
- Mountain
- Original MSRP
- $3,799.00
- Sizes
- S, M, L, XL
- Colors
- Lazuli Blue, Talus Grey
- Weight
- S: 5.1 | M: 5.2 | L: 5.3 | XL: 5.4
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 5 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001743
Frameset
| Frame Construction | Spot carbon frame — molding metal threads into carbon |
|---|---|
| Frame Material | Carbon |
| Rear Shock | Rockshox Deluxe Ultimate | 190x45 |
Wheels & Tires
| Wheel Size | 29 |
|---|
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| Seat tube | 370 mm | 400 mm | 440 mm | 480 mm |
| Top tube | 559 mm | 593 mm | 620 mm | 658 mm |
| Head tube | 84 mm | 100 mm | 117 mm | 126 mm |
| Head-tube angle | 65.2° | 65.2° | 65.2° | 65.2° |
| Seat-tube angle | 76.5° | 76.5° | 77° | 77.5° |
| Actual seat-tube angle | 72.7° | 72.7° | 73.3° | 73.8° |
| Chainstay / rear center | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1158 mm | 1195 mm | 1232 mm | 1265 mm |
| Bottom-bracket drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Bottom-bracket height | 337 mm | 337 mm | 337 mm | 337 mm |
| Reach | 415 mm | 445 mm | 475 mm | 505 mm |
| Stack | 600 mm | 615 mm | 630 mm | 645 mm |
| Standover height | 727 mm | 727 mm | 726 mm | 726 mm |
Geometry source: Spot first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
Small geometry
Archive context: Its reach of 415 mm sits toward the shorter end. Its stack of 600 mm sits somewhat lower than typical. Its wheelbase of 1158 mm sits somewhat shorter than typical.
Compared with 221 distinct mountain geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Medium geometry
Archive context: Its reach of 445 mm sits somewhat shorter than typical. Its wheelbase of 1195 mm sits somewhat shorter than typical. Its stack of 615 mm sits somewhat lower than typical.
Compared with 228 distinct mountain geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Large geometry
Archive context: The chainstay of 435 mm sits somewhat shorter than typical. Its bottom-bracket drop of 39 mm sits somewhat deeper than typical. The seat angle of 77° sits somewhat steeper than typical.
Compared with 221 distinct mountain geometries in the Large-equivalent size cohort from model years 2025–2027 in the Velopedia archive.X-Large geometry
Archive context: The seat angle of 77.5° sits toward the steeper end. The chainstay of 435 mm sits somewhat shorter than typical. Its bottom-bracket drop of 39 mm sits somewhat deeper than typical.
Compared with 194 distinct mountain geometries in the XL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Used-frameset inspection
If you’re buying this frameset used
Before buying: confirm the serial number and exact model, inspect frame and fork alignment, and inventory every included axle, hanger, clamp, headset part, cable guide and proprietary fitting.
Inspect the frame and fork →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- SuspensionAsk when the rear shock was last serviced. Check the shaft and seals for damage or oil, cycle the shock through its travel and test every suspension pivot for play.Evaluate the suspension →
- Included hardwareInventory every axle, hanger, clamp, headset part, cable guide, frame plug and proprietary fitting included with the frameset. Confirm replacement availability before treating a missing small part as insignificant.
Used-frameset inspection checklist 16 universal checks for a record with limited component data Open checklistClose checklist
The archived record does not contain enough component detail for a fully specification-informed frameset checklist. Use these universal checks on the frameset in front of you, inventory every included part and confirm exact interfaces before choosing components.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Spot Diggity 125 Frame Only · Frame/Frameset · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Spot carbon frame — molding metal threads into carbon
Suspension
Evaluate the suspension →Archived: Rear shock: Rockshox Deluxe Ultimate | 190x45
Alignment
Inspect the frame and fork →Frame interfaces
Inspect the bottom bracket and shell →Before accepting the frameset
Inspect the frame and fork →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
