2022 Specialized Tarmac SL6 Sport

Original specifications: geometry for 7 published sizes.

Share owner experience

Selling this bike? Get the spec link and selling options

At a glance

Model year
2022
Category
Road
Original MSRP
From $3,499.99
Sizes
44, 49, 52, 54, 56, 58, 61
Colors
Flo Red / Tarmac Black, Lagoon Blue / Cool Grey - Wild, Carbon/Smoke
Geometry
7 manufacturer sizes
In this record
19 specifications · 7 archived images · original MSRP · geometry
Archive ID
900003933
Campaign
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

7 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

44495254565861

Published colors

Flo Red / Tarmac BlackLagoon Blue / Cool Grey - WildCarbon/Smoke

Frameset

Frame ConstructionTarmac SL6, FACT 9r carbon, Rider-First Engineered™, threaded BB, clean routing, 12x142mm thru-axle, flat-mount disc
Frame MaterialCarbon Fiber
ForkFACT carbon, 12x100mm thru-axle, flat-mount disc
Fork MaterialCarbon Fiber

Drivetrain

ShiftersShimano 105 R7020, hydraulic disc
Front DerailleurShimano 105 R7000, braze-on
Rear DerailleurShimano 105 R7000-GS, medium cage
CranksetShimano 105 R7000, HollowTech 2, 11-speed; chainrings: 50/34T
Bottom BracketShimano Threaded BSA BB
CassetteShimano 105 R7000, 11-speed, 11-30t
ChainKMC X11 Extra Lightweight, 11-speed

Brakes

Brakes(F) Shimano 105, Hydraulic disc / (R) Shimano 105, Hydraulic disc

Cockpit & Contact Points

HandlebarSpecialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
StemSpecialized Pro SL, alloy, 4-bolt
SaddleBody Geometry Power Sport, steel rails
SeatpostS-Works FACT carbon 27.2mm, 20mm offset

Wheels & Tires

Wheels(F) DT Swiss R470 rim, 20mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples. / (R) DT Swiss R470 rim, 20mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, alloy freehub body, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples.
Front TireTurbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm
Rear TireTurbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm

Geometry

7 sizes · 20 measurements

Frame measurements by size.

All geometry measurements7 sizes · 20 measurements
Measurement44495254565861
Seat tube435 mm451 mm481 mm499 mm519 mm540 mm570 mm
Effective top tube493 mm511 mm535 mm544 mm566 mm581 mm599 mm
Head tube105 mm115 mm126 mm143 mm163 mm190 mm210 mm
Head-tube angle70.5°71.75°72.5°73°73.5°73.5°74°
Seat-tube angle76°75.5°74°74°73.5°73.5°73°
Chainstay / rear center410 mm410 mm410 mm410 mm410 mm410 mm410 mm
Wheelbase969 mm973 mm975 mm978 mm990 mm1005 mm1012 mm
Bottom-bracket drop74 mm74 mm74 mm72 mm72 mm72 mm72 mm
Bottom-bracket height266 mm266 mm266 mm268 mm268 mm268 mm268 mm
Reach365 mm375 mm380 mm384 mm395 mm402 mm408 mm
Stack500 mm514 mm527 mm544 mm565 mm591 mm612 mm
Standover height730 mm740 mm755 mm775 mm795 mm826 mm850 mm
Fork offset / rake47 mm47 mm47 mm44 mm44 mm44 mm44 mm
Front center571 mm574 mm577 mm579 mm591 mm606 mm613 mm
Trail71 mm63 mm58 mm58 mm55 mm55 mm52 mm
Fork length / axle-to-crown363 mm363 mm363 mm363 mm363 mm363 mm363 mm
Seatpost length300 mm300 mm350 mm350 mm350 mm400 mm400 mm
Crank length165 mm165 mm170 mm172.5 mm172.5 mm175 mm175 mm
Stem length70 mm80 mm90 mm100 mm100 mm110 mm110 mm
Handlebar width360 mm380 mm400 mm420 mm420 mm440 mm440 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes50/34T · 11–30T · 11-speed
Lowest1.13:1 Highest4.55:1 Total range401%
Estimated speed At 90 RPM Lowest gear8.1 mph Highest gear32.3 mph

Rear tire: 700C×26.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC X11 Extra Lightweight, 11-speed
Cassette · Original
Shimano 105 R7000, 11-speed, 11-30t Search: Shimano 105 R7000, 11-speed, 11-30t cassette
Front tire · Original
Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm Replacement search: 700cx26 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (6)
Bottom bracket · Original
Shimano Threaded BSA BB
Retailer offers · Affiliate links
Crankset · Original
Shimano 105 R7000, HollowTech 2, 11-speed; chainrings: 50/34T
Front derailleur · Original
Shimano 105 R7000, braze-on Search: Shimano FD-R7000 front derailleur
Retailer offers · Affiliate links
Rear derailleur · Original
Shimano 105 R7000-GS, medium cage Search: Shimano RD-R7000-GS rear derailleur
Shifters · Original
Shimano 105 R7020, hydraulic disc Search: Shimano ST-R7020 shifter
Handlebar · Original
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp

Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases.

Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
0 of 19 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2022 Specialized Tarmac SL6 Sport · Road · Published sizes: 44, 49, 52, 54, 56, 58, 61

Archived: Frame: Tarmac SL6, FACT 9r carbon, Rider-First Engineered™, threaded BB, clean routing, 12x142mm thru-axle, flat-mount disc · Fork: FACT carbon, 12x100mm thru-axle, flat-mount disc · Carbon Fiber

Archived: Shifters: Shimano 105 R7020, hydraulic disc · Front derailleur: Shimano 105 R7000, braze-on · Rear derailleur: Shimano 105 R7000-GS, medium cage · Crankset: Shimano 105 R7000, HollowTech 2, 11-speed; chainrings: 50/34T · Bottom bracket: Shimano Threaded BSA BB · Cassette: Shimano 105 R7000, 11-speed, 11-30t · Chain: KMC X11 Extra Lightweight, 11-speed

Archived: Brakes: (F) Shimano 105, Hydraulic disc / (R) Shimano 105, Hydraulic disc

Archived: Front tire: Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm · Rear tire: Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm

Controls and contact points

Archived: Handlebar: Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp · Stem: Specialized Pro SL, alloy, 4-bolt · Seatpost: S-Works FACT carbon 27.2mm, 20mm offset · Saddle: Body Geometry Power Sport, steel rails
