2020 Specialized Sirrus Expert Carbon

Original specifications: geometry for 5 published sizes.

Share owner experience

Selling this bike? Get the spec link and selling options

At a glance

Model year
2020
Category
Hybrid
Original MSRP
$2,100.00
Sizes
S, M, L, XL, XXL
Colors
Gloss Storm Grey/Rocket Red/Black Reflective
Geometry
5 manufacturer sizes
In this record
20 specifications · archived image · original MSRP · geometry
Archive ID
900003852
Model history 1 other year
Campaign
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMLXLXXL

Published colors

Gloss Storm Grey/Rocket Red/Black Reflective

Frameset

Frame ConstructionSpecialized FACT 9r carbon, Fitness Geometry, 12x142mm thru-axle, internal cable routing, flat-mount disc, Plug + Play fender mounts
Frame MaterialCarbon Fiber
ForkSpecialized FACT 9r carbon, 12x100mm thru-axle, flat-mount disc, Plug + Play fender mounts
Fork MaterialCarbon Fiber

Drivetrain

Rear DerailleurShimano 105 R7000 GS, medium cage, 11-speed
CranksetPraxis Alba; chainrings: 48/32T
Bottom BracketPraxis, Threaded bearings
CassetteShimano 105, 11-speed, 11-32t
ChainKMC X11, 11-speed w/ Missing Link™
PedalsPlatform, alloy

Brakes

Brakes(F) TRP Flow Set Control, hydraulic disc, resin pads, flat-mount, 160mm / (R) TRP Flow Set Control, hydraulic disc, resin pads, flat-mount, 160mm

Cockpit & Contact Points

HandlebarDouble-butted alloy, 9-degree backsweep, 31.8mm
StemSpecialized, 3D-forged alloy, 4-bolt, 7-degree rise
SaddleSpecialized Canopy Comp, hollow Cr-Mo rails, 155mm
SeatpostCarbon, single-bolt, 30.9mm

Wheels & Tires

Hubs(F) Alloy, 6-bolt disc, sealed bearing, 12x100mm thru-axle, 28h / (R) 6-bolt disc, sealed cartridge bearings, high-low flange, 12x142mm spacing, 28h
Rims700C disc, double-wall alloy, 30mm depth, 21mm internal width, disc-specific
SpokesStainless, 14g
Front TireEspoir Sport Reflect, 60 TPI, wire bead, double BlackBelt protection, 700x30mm
Rear TireEspoir Sport Reflect, 60 TPI, wire bead, double BlackBelt protection, 700x30mm

Geometry

5 sizes · 20 measurements

Frame measurements by size.

All geometry measurements5 sizes · 20 measurements
MeasurementSMLXLXXL
Seat tube416 mm452.8 mm483 mm533 mm563 mm
Effective top tube554 mm573 mm580 mm603 mm628 mm
Head tube143 mm169 mm186 mm223 mm246 mm
Head-tube angle70°71°71.5°72°72°
Seat-tube angle73.5°73.5°73.5°73.5°73°
Chainstay / rear center435 mm435 mm435 mm435 mm435 mm
Wheelbase1050 mm1060 mm1063 mm1082 mm1101 mm
Bottom-bracket drop70 mm70 mm70 mm70 mm70 mm
Bottom-bracket height275 mm275 mm275 mm275 mm275 mm
Reach371 mm384 mm386 mm398 mm410 mm
Stack602 mm631 mm649 mm687 mm709 mm
Standover height756 mm788 mm813 mm849 mm875 mm
Fork offset / rake51 mm51 mm51 mm51 mm51 mm
Front center625 mm635 mm637 mm656 mm675 mm
Trail71 mm65 mm62 mm58 mm58 mm
Fork length / axle-to-crown390 mm390 mm390 mm390 mm390 mm
Seatpost length300 mm350 mm350 mm350 mm400 mm
Crank length170 mm170 mm172.5 mm172.5 mm175 mm
Stem length80 mm90 mm90 mm100 mm100 mm
Handlebar width580 mm580 mm600 mm620 mm620 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes48/32T · 11–32T · 11-speed
Lowest1.00:1 Highest4.36:1 Total range436%
Estimated speed At 90 RPM Lowest gear7.2 mph Highest gear31.4 mph

Rear tire: 700C×30.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC X11, 11-speed w/ Missing Link™
Cassette · Original
Shimano 105, 11-speed, 11-32t Search: Shimano 105, 11-speed, 11-32t cassette
Front tire · Original
Espoir Sport Reflect, 60 TPI, wire bead, double BlackBelt protection, 700x30mm Replacement search: 700cx30 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (5)
Saddle · Original
Specialized Canopy Comp, hollow Cr-Mo rails, 155mm
Crankset · Original
Praxis Alba; chainrings: 48/32T
Rear derailleur · Original
Shimano 105 R7000 GS, medium cage, 11-speed Search: Shimano RD-R7000 rear derailleur
Stem · Original
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Seatpost · Original
Carbon, single-bolt, 30.9mm
