Velopedia Bicycle Archive
1995 Bianchi Carbon Virata
Road race & triathlon bicycle from the Velopedia specification archive.
- Original MSRP
- $1,195.00
- Sizes
- 49 cm, 51 cm, 53 cm, 55 cm, 57 cm, 59 cm, 61 cm, 63 cm
- Colors
- Red fade
- Weight
- 22.2
- Geometry
- Legacy reference · Ride analysis
- Archive ID
- 34007
Image not available
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
The 218% cassette range describes the available gearing more clearly than the component-group name alone. Carbon construction changes the inspection emphasis from metal-style dents and corrosion to impact damage, ripples and overtightened clamp areas. 700C · 622 mm identifies the rim diameter, while tire width and available frame or fork clearance remain separate compatibility questions.
Gearing
218% cassette range
Calculated from the published 11–24-tooth sprocket span.
Frame material
Carbon / composite
Look for impact damage and clamp marks rather than metal-style dents or rust.
Wheel standard
700C · 622 mm
The label fixes rim diameter, not tire width or available frame and fork clearance.
Published weight
22.2
Frame size, pedals, tire setup and production substitutions can change the measured result.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 7-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 1995 Bianchi Carbon Virata · Road race & triathlon · Published sizes: 49 cm, 51 cm, 53 cm, 55 cm, 57 cm, 59 cm, 61 cm, 63 cm
Frame and fork
Inspect the frame and fork →Archived: Frame: Lugged carbon fiber · Fork: Akisu · Chromoly, butted, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano RSX STI · Shifters: Shimano RSX STI Dual Control · Front derailleur: Shimano RSX, bottom-pull · Rear derailleur: Shimano RSX · Crankset: Shimano RSX, 36/46 teeth · Rear cogs: 7-speed, 11 - 24 teeth · Chain: Shimano CN-IG50, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano RSX Dual Pivot brakes, Shimano RSX levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic 204 SUP UB, 32-hole · Hubs: Shimano RSX · Front tire: 700 x 24c Ritchey Road Force
Controls and contact points
Archived: Headset: 1" Tien Hsin TH-305 · Handlebar: SR Modolo Bend anatomic · Stem: Hsin Lung chromoly · Seatpost: Kalloy SP-243, 27.2 mm diameter · Saddle: Ritchey Vector · Pedals: Shimano PD-A525 SPD (clipless)
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | Lugged carbon fiber |
|---|---|
| Frame Material | Carbon fiber main triangle / Tange Prestige rear stays |
| Fork | Akisu |
| Fork Material | Chromoly, butted, unicrown crown |
Drivetrain
| Component Group | Shimano RSX STI |
|---|---|
| Shifters | Shimano RSX STI Dual Control |
| Front Derailleur | Shimano RSX, bottom-pull |
| Rear Derailleur | Shimano RSX |
| Crankset | Shimano RSX, 36/46 teeth |
| Rear Cogs | 7-speed, 11 - 24 teeth |
| Chain | Shimano CN-IG50, 1/2 x 3/32" |
| Pedals | Shimano PD-A525 SPD (clipless) |
Brakes
| Brakes | Shimano RSX Dual Pivot brakes, Shimano RSX levers |
|---|
Cockpit & Contact Points
| Headset | 1" Tien Hsin TH-305 |
|---|---|
| Handlebar | SR Modolo Bend anatomic |
| Handlebar Extensions | N/A |
| Stem | Hsin Lung chromoly |
| Saddle | Ritchey Vector |
| Seatpost | Kalloy SP-243, 27.2 mm diameter |
Wheels & Tires
| Hubs | Shimano RSX |
|---|---|
| Rims | Mavic 204 SUP UB, 32-hole |
| Spokes | Stainless steel, 2.0 mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 24c Ritchey Road Force |
| Wheel Size | 700c wheels |
Historical reference geometry
Geometry
Historical model-level geometry recovered from Velopedia’s original archive database. The source does not identify which listed frame size this reference describes, so fit interpretation is intentionally limited and no size-normalized Archive Context is generated.
| Measurement | Legacy reference |
|---|---|
| Top tube | 570 mm |
| Head-tube angle | 73° |
| Seat-tube angle | 74° |
| Chainstay / rear center | 406 mm |
| Wheelbase | 987 mm |
| Fork offset / rake | 45 mm |
Geometry source: Historical archive database — model-level reference geometry. The historical source provides one model-level geometry set and does not identify the corresponding frame size.
Geometry interpretation
What this geometry means
Legacy reference geometry
Fit reference
The historical source lists a 570 mm top-tube length, but it does not identify which frame size this model-level reference describes or whether the historical field was measured horizontally. Treat it as an archival frame reference rather than a size-specific fit recommendation. Its 74° seat-tube angle describes the reference frame’s seat-line orientation. Actual seated position still depends on frame size, saddle height and fore-aft adjustment.
Handling tendencies
The 73° head angle points to moderate steering geometry. Wheelbase is listed at 987 mm, but because the historical source does not identify frame size, it is retained as a model reference rather than used for a size-normalized handling conclusion. Fork offset is listed at 45 mm. Offset works with head angle and wheel size to determine trail, so it is useful steering evidence even though the archive does not provide enough information here to calculate trail reliably.
Period context
At 73°, the head angle sits somewhat slacker than typical among road geometries represented in Velopedia for this period. Its 74° seat angle is toward the steeper end among the same-period road references.
This is historical model-level reference geometry, not a known frame-size geometry table or a ride test. Frame size, rider proportions, cockpit setup, tires, suspension and components can materially change fit and handling.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
