2022 Specialized Sirrus X 3.0

Original specifications: geometry for 6 published sizes.

Share owner experience

Selling this bike? Get the spec link and selling options

At a glance

Model year
2022
Category
Hybrid
Original MSRP
$999.99
Sizes
XXS, XS, S, M, L, XL
Colors
Gloss Flake Silver / Ice Yellow / Satin Black Reflective, Satin Cast Black / Black / Satin Black Reflective, Satin Maroon / Black / Satin Black Reflective
Geometry
6 manufacturer sizes
In this record
22 specifications · 8 archived images · original MSRP · geometry
Archive ID
900004159
Model history 3 other years
Campaign
Original buildAluminum

Manufacturer catalog

Published sizes and colors

6 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XXSXSSMLXL

Published colors

Gloss Flake Silver / Ice Yellow / Satin Black ReflectiveSatin Cast Black / Black / Satin Black ReflectiveSatin Maroon / Black / Satin Black Reflective

Frameset

Frame ConstructionSpecialized A1 Premium Aluminum, Fitness Geometry, butted tubing, internal cable routing, flat-mount disc, quick-release, Plug + Play rack/fender mounts
Frame MaterialAluminum
ForkA1 Premium Aluminum, flat-mount disc, Plug + Play fender mounts, low rider rack mounts, quick-release
Fork MaterialAluminum

Drivetrain

ShiftersmicroSHIFT TrailTrigger Pro, 9-speed
Rear DerailleurmicroSHIFT Advent, 1x9 w/ clutch
CranksetForged aluminum arms, 2-piece, 24mm spindle, Narrow-wide steel chainring; chainrings: 40T
Bottom BracketThreaded BSA 68mm, 24mm spindle
BB Shell Width68 mm
CassettemicroSHIFT Advent, 9-speed, 11-42t
ChainKMC X9, 9-speed w/ Missing Link™
PedalsSpecialized Body Geometry Fitness, platform, plastic

Brakes

Brakes(F) Tektro HD-R280, hydraulic disc, resin pads, flat-mount, 160mm / (R) Tektro HD-R280, hydraulic disc, resin pads, flat-mount, 160mm

Cockpit & Contact Points

HandlebarAlloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm
Stem3D-forged alloy, 31.8mm, 7-degree rise
SaddleBridge Sport, Steel rails, 155/143mm
SeatpostAlloy, 12mm offset, 2-bolt clamp, 27.2mm

Wheels & Tires

Hubs(F) Alloy, 6-bolt disc, loose ball bearing, quick-release, 32h / (R) Alloy, 6-bolt disc, 8-/9-speed freehub, loose ball bearing, quick-release, 32h
Rims700C disc, double-wall alloy, 22mm depth, 21mm internal width, 32h
SpokesStainless, 14g
Front TirePathfinder Sport, 700x42
Rear TirePathfinder Sport, 700x42

Geometry

6 sizes · 20 measurements

Frame measurements by size.

All geometry measurements6 sizes · 20 measurements
MeasurementXXSXSSMLXL
Seat tube360 mm395 mm440 mm470 mm510 mm530 mm
Effective top tube532 mm552 mm560 mm574 mm582 mm602 mm
Head tube121 mm139 mm147 mm175 mm191 mm217 mm
Head-tube angle69.5°70°70°71°71°71°
Seat-tube angle73.5°73.5°73.5°73.5°73.5°73.5°
Chainstay / rear center440 mm440 mm440 mm440 mm440 mm440 mm
Wheelbase1036 mm1053 mm1061 mm1076 mm1096 mm1067 mm
Bottom-bracket drop70 mm70 mm70 mm70 mm70 mm70 mm
Bottom-bracket height288 mm288 mm288 mm288 mm288 mm288 mm
Reach373 mm388 mm393 mm398 mm402 mm414 mm
Stack536 mm555 mm563 mm593 mm608 mm633 mm
Standover height702 mm725 mm755 mm785 mm815 mm837 mm
Fork offset / rake51 mm51 mm51 mm51 mm51 mm51 mm
Front center606 mm623 mm631 mm636 mm645 mm665 mm
Trail79 mm76 mm76 mm69 mm69 mm69 mm
Fork length / axle-to-crown395 mm395 mm395 mm395 mm395 mm395 mm
Seatpost length300 mm300 mm350 mm350 mm400 mm400 mm
Crank length165 mm165 mm170 mm170 mm175 mm175 mm
Stem length60 mm60 mm70 mm80 mm90 mm100 mm
Handlebar width680 mm680 mm680 mm680 mm680 mm680 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes40T · 11–42T · 9-speed
Lowest0.95:1 Highest3.64:1 Total range382%
Estimated speed At 90 RPM Lowest gear7.1 mph Highest gear27.1 mph

Rear tire: 700C×42.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
