2022 Specialized Sirrus 1.0

Original specifications: geometry for 6 published sizes.

Share owner experience

Selling this bike? Get the spec link and selling options

At a glance

Model year
2022
Category
Hybrid
Original MSRP
$649.99
Sizes
XXS, XS, S, M, L, XL
Colors
Gloss Black / Charcoal / Satin Black Reflective, Gloss Cool Grey / Smoke / Satin Black Reflective, Gloss Sky Blue / Cast Blue / Satin Black Reflective
Geometry
6 manufacturer sizes
In this record
23 specifications · 6 archived images · original MSRP · geometry
Archive ID
900004157
Model history 2 other years
Campaign
Original buildAluminum

Manufacturer catalog

Published sizes and colors

6 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XXSXSSMLXL

Published colors

Gloss Black / Charcoal / Satin Black ReflectiveGloss Cool Grey / Smoke / Satin Black ReflectiveGloss Sky Blue / Cast Blue / Satin Black Reflective

Frameset

Frame ConstructionSpecialized A1 Premium Aluminum, Fitness Geometry, Butted tubing, Internal Cable Routing, V-Brake, Quick-Release, Plug + Play rack/fender mounts
Frame MaterialAluminum
ForkHi-Ten steel, V-Brake, Plug + Play fender mounts, low rider rack mounts, quick-release
Fork MaterialSteel

Drivetrain

ShiftersmicroSHIFT TS39 Trigger shift, 7-speed
Front DerailleurMicroSHIFT FD-T202, Band-clamp
Rear DerailleurmicroSHIFT RD-M26S, 7-speed
CranksetForged aluminum arms, 3-piece, 46/30T
Bottom BracketBSA, square-taper, 68mm
BB Shell Width68 mm
CassetteSunRace, 7-Speed, 11-34t
ChainKMC X8 w/ Missing Link™
PedalsSpecialized Body Geometry Fitness, platform, plastic

Brakes

Brakes(F) V-brake, linear pull / (R) V-brake, linear pull

Cockpit & Contact Points

HandlebarDouble-butted alloy, 5-degree backsweep, 25.4mm
StemSpecialized Flowset, integrated, 3D-forged alloy, 4-bolt, 12-degree rise, 31.8mm clamp
SaddleBridge Sport, Steel rails, 155/143mm
SeatpostAlloy, 12mm offset, 2-bolt clamp, 27.2mm

Wheels & Tires

Hubs(F) Alloy, loose ball bearing, quick-release, 32h / (R) Alloy, loose ball bearings, quick-release, 7-speed freehub, 32h
Rims700C rim brake, double-wall alloy, 22mm depth, 21mm internal width, rim brake
SpokesStainless, 14g
Front TireRoadSport, Wire bead, Blackbelt/Endurant Casing, 700x32c
Rear TireRoadSport, Wire bead, Blackbelt/Endurant Casing, 700x32c

Geometry

6 sizes · 20 measurements

Frame measurements by size.

All geometry measurements6 sizes · 20 measurements
MeasurementXXSXSSMLXL
Seat tube360 mm395 mm440 mm470 mm510 mm530 mm
Effective top tube531 mm552 mm559 mm573 mm582 mm601 mm
Head tube121 mm139 mm147 mm175 mm191 mm217 mm
Head-tube angle69.5°70°70°71°71°71°
Seat-tube angle73.5°73.5°73.5°73.5°73.5°73.5°
Chainstay / rear center440 mm440 mm440 mm440 mm440 mm440 mm
Wheelbase1053 mm1061 mm1066 mm1075 mm1096 mm1036 mm
Bottom-bracket drop70 mm70 mm70 mm70 mm70 mm70 mm
Bottom-bracket height278 mm278 mm278 mm278 mm278 mm278 mm
Reach373 mm388 mm393 mm398 mm402 mm414 mm
Stack536 mm555 mm562 mm593 mm608 mm632 mm
Standover height692 mm715 mm745 mm775 mm805 mm827 mm
Fork offset / rake51 mm51 mm51 mm51 mm51 mm51 mm
Front center605 mm622 mm630 mm635 mm645 mm665 mm
Trail75 mm72 mm72 mm65 mm65 mm65 mm
Fork length / axle-to-crown395 mm395 mm395 mm395 mm395 mm395 mm
Seatpost length300 mm300 mm350 mm350 mm400 mm400 mm
Crank length170 mm170 mm170 mm170 mm175 mm175 mm
Stem length60 mm60 mm75 mm75 mm90 mm110 mm
Handlebar width580 mm580 mm600 mm600 mm620 mm620 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes46/30T · 11–34T · 7-speed
Lowest0.88:1 Highest4.18:1 Total range474%
Estimated speed At 90 RPM Lowest gear6.4 mph Highest gear30.2 mph

Rear tire: 700C×32.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC X8 w/ Missing Link™
Cassette · Original
SunRace, 7-Speed, 11-34t
Pedals · Original
Specialized Body Geometry Fitness, platform, plastic
More parts (4)
Front derailleur · Original
MicroSHIFT FD-T202, Band-clamp
Rear derailleur · Original
microSHIFT RD-M26S, 7-speed
Stem · Original
Specialized Flowset, integrated, 3D-forged alloy, 4-bolt, 12-degree rise, 31.8mm clamp
Seatpost · Original
Alloy, 12mm offset, 2-bolt clamp, 27.2mm
Retailer offers · Affiliate links

Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases.

Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
0 of 19 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2022 Specialized Sirrus 1.0 · Hybrid · Published sizes: XXS, XS, S, M, L, XL

Archived: Frame: Specialized A1 Premium Aluminum, Fitness Geometry, Butted tubing, Internal Cable Routing, V-Brake, Quick-Release, Plug + Play rack/fender mounts · Fork: Hi-Ten steel, V-Brake, Plug + Play fender mounts, low rider rack mounts, quick-release · Steel

Archived: Shifters: microSHIFT TS39 Trigger shift, 7-speed · Front derailleur: MicroSHIFT FD-T202, Band-clamp · Rear derailleur: microSHIFT RD-M26S, 7-speed · Crankset: Forged aluminum arms, 3-piece, 46/30T · Bottom bracket: BSA, square-taper, 68mm · Cassette: SunRace, 7-Speed, 11-34t · Chain: KMC X8 w/ Missing Link™

Archived: Brakes: (F) V-brake, linear pull / (R) V-brake, linear pull

Archived: Rims: 700C rim brake, double-wall alloy, 22mm depth, 21mm internal width, rim brake · Hubs: (F) Alloy, loose ball bearing, quick-release, 32h / (R) Alloy, loose ball bearings, quick-release, 7-speed freehub, 32h · Front tire: RoadSport, Wire bead, Blackbelt/Endurant Casing, 700x32c · Rear tire: RoadSport, Wire bead, Blackbelt/Endurant Casing, 700x32c

Controls and contact points

Archived: Handlebar: Double-butted alloy, 5-degree backsweep, 25.4mm · Stem: Specialized Flowset, integrated, 3D-forged alloy, 4-bolt, 12-degree rise, 31.8mm clamp · Seatpost: Alloy, 12mm offset, 2-bolt clamp, 27.2mm · Saddle: Bridge Sport, Steel rails, 155/143mm · Pedals: Specialized Body Geometry Fitness, platform, plastic

Before and during the test ride
