2019 Specialized Alibi C
Original specifications: geometry for 4 published sizes.
Selling this bike? Get the spec link and selling options
At a glance
- Model year
- 2019
- Category
- Hybrid
- Original MSRP
- $500.00
- Sizes
- S, M, L, XL
- Colors
- Satin Cast Blue/Rocket Red Reflective, Satin Light Silver/Black Reflective
- Geometry
- 4 manufacturer sizes
- In this record
- 18 specifications · 2 archived images · original MSRP · geometry
- Archive ID
- 900003410
Original buildAluminum
Frameset
| Frame Construction | Specialized A1 Premium Aluminum, formed tubes, fender/rack mounts |
|---|---|
| Frame Material | Aluminum |
| Fork | Hi-Ten, V-brake mounts |
Drivetrain
| Shifters | Shimano Acera, 7-speed |
|---|---|
| Rear Derailleur | Shimano Tourney, 7-speed |
| Crankset | Forged alloy, 130mm BCD; chainrings: 42T |
| Bottom Bracket | BSA, square-taper, cartridge bearings |
| Cassette | Shimano Tourney freewheel, 7-speed, 14-34t |
| Chain | KMC Z51 EPT, anti-rust coating, 7-speed |
| Pedals | Specialized City, platform |
Brakes
| Brakes | (F) V-brake, linear pull / (R) V-brake, linear pull |
|---|
Cockpit & Contact Points
| Handlebar | 640mm width, 15-degree backsweep, 80mm rise, 31.8mm |
|---|---|
| Stem | Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
| Saddle | Body Geometry Comfort Gel, 200mm |
| Seatpost | Spring suspension, alloy, 27.2mm, 2-bolt clamp |
Wheels & Tires
| Wheels | (F) Alibi V-Brake / (R) Alibi V-Brake |
|---|---|
| Front Tire | Nimbus Airless, 700x38mm |
| Rear Tire | Nimbus Airless, 700x38mm |
Geometry
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
All geometry measurements4 sizes · 17 measurements
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Effective top tube | 585 mm | 607 mm | 628 mm | 652 mm |
| Head tube | 160 mm | 185 mm | 210 mm | 240 mm |
| Head-tube angle | 70° | 70° | 70° | 70° |
| Seat-tube angle | 73° | 73° | 73° | 73° |
| Chainstay / rear center | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1096 mm | 1119 mm | 1144 mm | 1169 mm |
| Bottom-bracket drop | 70 mm | 70 mm | 65 mm | 65 mm |
| Reach | 405 mm | 420 mm | 435 mm | 450 mm |
| Stack | 575 mm | 599 mm | 617 mm | 645 mm |
| Standover height | 714 mm | 766 mm | 790 mm | 834.5 mm |
| Fork offset / rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Front center | 661 mm | 684 mm | 707 mm | 732 mm |
| Trail | 75 mm | 75 mm | 75 mm | 75 mm |
| Seatpost length | 350 mm | 350 mm | 350 mm | 350 mm |
| Crank length | 165 mm | 170 mm | 175 mm | 175 mm |
| Stem length | 60 mm | 70 mm | 90 mm | 100 mm |
| Handlebar width | 640 mm | 640 mm | 640 mm | 640 mm |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
