2017 Specialized Amira Comp

Original specifications: geometry for 5 published sizes.

Share owner experience

Selling this bike? Get the spec link and selling options

At a glance

Model year
2017
Category
Road
Sizes
44, 48, 51, 54, 56
Colors
Satin Carbon/ Charcoal, Satin Turquoise/ Hyper Green/ Black
Geometry
5 manufacturer sizes
In this record
19 specifications · 2 archived images · geometry
Archive ID
900003263
Model history 3 other years
Campaign
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

5 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

4448515456

Published colors

Satin Carbon/ CharcoalSatin Turquoise/ Hyper Green/ Black

Frameset

Frame ConstructionFACT 9r carbon, women's carbon layup & competitive geometry, tapered head tube, OSBB, internal routing, 130mm spacing
Frame MaterialCarbon Fiber
ForkFACT carbon, full monocoque
Fork MaterialCarbon Fiber

Drivetrain

ShiftersShimano Ultegra 6800, 11-speed
Front DerailleurShimano Ultegra 6800, 11-speed, braze-on
Rear DerailleurShimano Ultegra 6800, 11-speed, braze-on
CranksetShimano Ultegra Compact; chainrings: 50/34T
Bottom BracketShimano Ultegra
CassetteShimano 105 5800, 11-speed, 11/28t
ChainKMC X11, 11-speed

Brakes

Brakes(F) Shimano Ultegra / (R) Shimano Ultegra

Cockpit & Contact Points

HandlebarSpecialized Women's Comp Shallow Drop, alloy, 123mm drop, 75mm reach
Stem3D-forged alloy, 7-degree rise
SaddleBody Geometry Oura Comp, hollow Cr-Mo rails, 155mm
SeatpostSpecialized Comp carbon, single bolt

Wheels & Tires

Wheels(F) DT Swiss R460, QR / (R) DT Swiss R460, QR
Front TireTurbo Pro, 700x23mm, 127TPI, folding bead, BlackBelt protection
Rear TireTurbo Pro, 700x23mm, 127TPI, folding bead, BlackBelt protection

Geometry

5 sizes · 19 measurements

Frame measurements by size.

All geometry measurements5 sizes · 19 measurements
Measurement4448515456
Seat tube390 mm420 mm460 mm490 mm510 mm
Effective top tube491 mm502 mm515 mm535 mm547 mm
Head tube105 mm115 mm125 mm145 mm165 mm
Head-tube angle70.5°71.25°72°72°72°
Seat-tube angle76°76°76°74°74°
Chainstay / rear center405 mm405 mm405 mm405 mm408 mm
Wheelbase970 mm974 mm976 mm982 mm994 mm
Bottom-bracket drop73 mm73 mm73 mm73 mm72 mm
Bottom-bracket height269 mm269 mm269 mm269 mm270 mm
Reach365 mm371 mm378 mm378 mm380 mm
Stack504 mm516 mm529 mm548 mm565 mm
Fork offset / rake51 mm51 mm49 mm49 mm49 mm
Front center576 mm580 mm582 mm588 mm596 mm
Trail67 mm62 mm59 mm59 mm59 mm
Fork length / axle-to-crown369 mm369 mm369 mm369 mm369 mm
Seatpost length350 mm350 mm400 mm400 mm400 mm
Crank length165 mm165 mm170 mm170 mm172.5 mm
Stem length70 mm80 mm90 mm100 mm100 mm
Handlebar width360 mm380 mm400 mm400 mm420 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes50/34T · 11–28T · 11-speed
Lowest1.21:1 Highest4.55:1 Total range374%
Estimated speed At 90 RPM Lowest gear8.6 mph Highest gear32.0 mph

Rear tire: 700C×23.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC X11, 11-speed
Retailer offers
Front tire · Original
Turbo Pro, 700x23mm, 127TPI, folding bead, BlackBelt protection Replacement search: 700cx23 bicycle tire Before ordering: Check rim type and tire clearance.
Bottom bracket · Original
Shimano Ultegra
More parts (6)
Crankset · Original
Shimano Ultegra Compact; chainrings: 50/34T
Front derailleur · Original
Shimano Ultegra 6800, 11-speed, braze-on Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Rear derailleur · Original
Shimano Ultegra 6800, 11-speed, braze-on Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
Shimano Ultegra 6800, 11-speed Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Handlebar · Original
Specialized Women's Comp Shallow Drop, alloy, 123mm drop, 75mm reach
Seatpost · Original
Specialized Comp carbon, single bolt

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
0 of 19 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2017 Specialized Amira Comp · Road · Published sizes: 44, 48, 51, 54, 56

Archived: Frame: FACT 9r carbon, women's carbon layup & competitive geometry, tapered head tube, OSBB, internal routing, 130mm spacing · Fork: FACT carbon, full monocoque · Carbon Fiber

Archived: Shifters: Shimano Ultegra 6800, 11-speed · Front derailleur: Shimano Ultegra 6800, 11-speed, braze-on · Rear derailleur: Shimano Ultegra 6800, 11-speed, braze-on · Crankset: Shimano Ultegra Compact; chainrings: 50/34T · Bottom bracket: Shimano Ultegra · Cassette: Shimano 105 5800, 11-speed, 11/28t · Chain: KMC X11, 11-speed

Archived: Brakes: (F) Shimano Ultegra / (R) Shimano Ultegra

Archived: Wheels: (F) DT Swiss R460, QR / (R) DT Swiss R460, QR · Front tire: Turbo Pro, 700x23mm, 127TPI, folding bead, BlackBelt protection · Rear tire: Turbo Pro, 700x23mm, 127TPI, folding bead, BlackBelt protection

Controls and contact points

Archived: Handlebar: Specialized Women's Comp Shallow Drop, alloy, 123mm drop, 75mm reach · Stem: 3D-forged alloy, 7-degree rise · Seatpost: Specialized Comp carbon, single bolt · Saddle: Body Geometry Oura Comp, hollow Cr-Mo rails, 155mm
